High Tech Horizontal Sand Mill Machine Wet Grinding / Dispersing Easy Operation

High-tech product Wet grinding & Dispersing Horizontal Sand Mill Machine

Working Principle
The delivery pump circulates the materials in the tank and the materials in the grinding chamber. The turbine rotors drive the grinding medium inside the grinding chamber to do irregular movements in all direction to put the materials under
the. action of constant collision and friction. At same time, the materials are separated from the grinding media by the sieve and keep circulating from the tank to the grinding chamber to obtain smaller particle size, narrower particle size range.
Characteristics
• Adopts double acting mechanical seal, lubricating liquid dissolves with product, safety and reliability.
• Multiple material can be chosen for dispersing rotors , catering to customer requirements for product color difference.
• Body is convenient to be disassembled, easy to clean and for different color products.
•The machine is easy to do operation, good reliability and full specification. It is a most widely used liquid grinding machine in the market with mature performance and structure. The machine uses dual-end mechanical seal with closed self-lubricate system with good reliability and durability. The machine is also with temperature, pressure monitor and protection to ensurethe quality of the finished product. It is with the advantages such as high grinding efficiency, good grinding fineness, wide. application and good anti-abrasiveness etc.
•Materials Viscosity : ≤60000 cps
•Production Capacity: 20-1000L
•Application Industry : Suitable for dispersing, grinding materials in a variety of applications such as biology, pharmacy, cosmetic, food, paint, ink, color paste, dyestuff, fertilizer ,Lithium-ion battery cathode and anode material etc

Product  Advantages

• Ultrafine grinding and dispersing technology, applicable for materials with different viscosities
• Ceramic (zirconia/ carborundum) grinding chamber to avoid pollution and improve purity of the material
• Mechanical seal with special design to facilitate stable operation
• Patented centrifugal discharge solution of Boyee which solves the blockage problem
• Better evenness for grinding with narrower peak of the distribution curve
• Independent electric box, optimized process control system and intellectual technology to help monitor the operation data
• Unique design for profile with reasonable structure and small space occupancy
• Equipment remain stale and quiet with little noise while running
• Ultrafine grinding media (as fine as 0.05mm) can be utilized without leakage or damage to the surface properties of the material

Operational safty
     For increased operationaly safety,The mechanical seal fluid is monitored continously.These data can be documented and used for predictive maintenance to ensure high availability of the machine
