3L small scale Horizontal Bead Mill for high-tech product developed researching
3L small scale Horizontal Bead Mill for high-tech product developed researching
Application
Suitable for the grinding and dispersing of liquid-phase particulate materials such as surface coatings, dyes, pigments, printing inks, pesticides and paper industries.
The machinery is designed for continuous production with efficient grinding and dispersing, suitable for various viscosity materials. The grinding mechanism is totally enclosed and solvent loss is cut down to minimum Specifically designed to incorporate rotating turbine rotors type agitation.
Specially machined slots encourage the bead mass to concentrate against the product flow giving the very best grinding action. Complete with starters, feed pump and safety switches on over pressure and over temperature and media separation is obtained by centrifugal force separation system.
Product Features
- Simple profile, compact conformation and easy operation
- Different choices for material of turbine, such as wear-resistant metal, ceramic and polyurethane
- Dynamic separation or centrifugial separation with big flow, suitable for continuous production or batch production
- Double mechanical seal with high reliability
- Pressure induction protective device and electric protective system, secure and reliable
- Full-ceramic grinding tools to avoid metallic pollution
Other Series
|
Model
|
Volume (L)
|
Motor Power (KW)
|
Medium Size (mm)
|
Weight (KG)
|
Dimension (mm)
|
|
NMM-10
|
10
|
18.5
|
0.3-1
|
1280
|
1800*1200*1550
|
|
NMM-30
|
30
|
45
|
0.3-1
|
1850
|
1800*1300*1800
|
|
NMM-60
|
58
|
75
|
0.3-1
|
2480
|
3290*1478*1950
|
|
NMM-90
|
98
|
75-90
|
0.3-1
|
3050
|
3290*1478*1950
|
|
NMM-150
|
120-180
|
160
|
0.3-1
|
5280
|
4500*1700*2400
|
