60L Horizontal Pin Type Boyee Agitator Bead Mill Powerful Cooling Efficiency
Boyee Agitator Bead Mill for Best quality and after-sale service
Application
Horizontal sand mill ,as known as agitator bead mill ,is a continuous working for ultramicron grinding and dispersing machine with horizontal cylinder .It apply to grind dispersing liquid, as well as used in dispersing high-viscosity liquid.
Horizontal sand mill is widely used for coatings, pigment, oil paint ,ink, medicine, food, cosmetics, pesticide, electronic materials, ceramics’ print oil and other industries, this machine is specially for grinding and dispersing the productions that is high-viscosity but exquisite granularity.
structure
Full ceramic structure,high wearing reistance,no contaminations
Multiple cooling system,powerful cooling efficiency
Efficiency separation system,not block or break beads, discharging more moothly and more quickly.
High energy intensive output,even smaller grinding fineness
With excellent lengthand diameter ratio,narrower particle ize distribution.
Product Advantages
- Ultrafine grinding and dispersing technology, applicable for materials with different viscosities
- Ceramic (zirconia/ carborundum) grinding chamber to avoid pollution and improve purity of the material
- Mechanical seal with special design to facilitate stable operation
- Patented centrifugal discharge solution of Boyee which solves the blockage problem
- Better evenness for grinding with narrower peak of the distribution curve
- Independent electric box, optimized process control system and intellectual technology to help monitor the operation data
- Unique design for profile with reasonable structure and small space occupancy
- Equipment remain stale and quiet with little noise while running
- Ultrafine grinding media (as fine as 0.05mm) can be utilized without leakage or damage to the surface properties of the material
Operational safty
For increased operationaly safety,The mechanical seal fluid is monitored continously.These data can be documented and used for predictive maintenance to ensure high availability of the machine
Other Series
Model | Volume (L) | Motor Power (KW) | Medium Size (mm) | Weight (KG) | Dimension (mm) |
NMM-10 | 10 | 18.5 | 0.3-1 | 1280 | 1800*1200*1550 |
NMM-30 | 30 | 45 | 0.3-1 | 1850 | 1800*1300*1800 |
NMM-60 | 58 | 75 | 0.3-1 | 2480 | 3290*1478*1950 |
NMM-90 | 98 | 75-90 | 0.3-1 | 3050 | 3290*1478*1950 |
NMM-150 | 120-180 | 160 | 0.3-1 | 5280 | 4500*1700*2400 |
