Intelligent On Line Benzene Industrial Gas Detectors 0-100ppm Light & Sound Alarm

Intelligent On-Line Benzene Gas Detector 0-100ppm With Light&Sound Alarm 4-20mA&Rs485 Signal Output

Product Introduction:

Benzene Gas Detector features a high-performance intelligent gas sensor, an on-line detection instrument for continuous on-line monitoring of flammable gases and toxic and harmful gases. The detector's overall explosion-proof structure, signal stability, sensitivity, and precision are high, using more than 30 kinds of smart sensors that can be plug-and-play.

Benzene Gas Detector can realize real-time concentration display on the computer through gas alarm controller and monitoring and management software, and can also pass real-time data and alarm status to the safety control center through the optional wireless module.

Product Function:

The response time is short and the detection error is low and the resolution is high.
Configure the infrared remote control;
4-20mA signal and standard RS485 digital signal output;
Intelligent temperature and humidity and zero-point compensation algorithm;
Unique LCD with backlight design;
Support PPM and mg/m3, %VOL and mg/L concentration units to switch freely;

Technical parameter:

Detection principle: PID
Measurement range: 0-100ppm
Score: 0.01ppm
Sampling method: Free diffusion
Installation: Wall-mounted
Value error: ≤± 3% FS
Re-complexity: ≤±1%
Zero Drift: ≤±1%
Response time: ≤20 seconds (T90)
Recovery time: ≤ 30 seconds
Power supply: 12 to 30VDC
Power rate: ≤2.5 W (DC24V)
Environmental pressure: 86kPa to 106kPa
