HDX-09B 16 Core Fiber Optic Termination Box 2X16 Core FTTX Fiber Optic Box Splitter Box
Price:
USD/6.5-20.5/PCS
MOQ:
10
Delivery Time:
Negotiable
Brand:
HODCY
Product Description
HDX-09B 16 Core Fiber Optic Termination Box 2X16 Core FTTX Fiber Optic Box Splitter Box Black
Features:
Features:
Industry Standard User Interface, be made of high impact plastic.
Can accommodate 1x4 & 1X8 & 1X16PLC splitter.
Anti-UV, Ultra violet resistant and rainfall resistant.
Up to 24 FTTH drops.
Wall and pole mountable.
2 inlet ports, 8~24 outlet ports.
Special cable fixed position, ensure the cable fixed pulled off force after not less than 50 N.
Job stress: 70 kpa to 108 kpa;
Using the temperature:- 40 ~ + 60 ºC
Relative humidity: ≤95% (+ 40 ºC).
Protection grade: IP55.
Application:
widely used in FTTH access network.
Telecommunication Networks
CATV Networks
Data communications Networks
Local Area Networks
Specifications:
| Operating temperature: | -40°C - +70°C |
| Storage temperature: | -40°C - +70°C |
| Relative humidity: | ≤90% (when the temperature is below 30°C) |
| Atmosphere pressure | 62Kpa - 106Kpa |
| Insulating resistance: | ≥2x104 MΩ / 500V (DC) |
| Insertion loss: | IL≤0.30dB(PC),IL≤0.30dB(APC) |
| Return loss: | PC≥40.0dB ,UPC≥50.0dB,APC≥60.0dB |
| Interchangeability | ≤0.20dB |
