ASTM B348 Titanium Bar For Medical Use H13
Polished ASTM B348 Titanium Alloy Bar For Chemical Processing / Medical Industry
Heat Treatment
Titanium alloys are heat treated for a number of reasons, the main ones being to increase strength by solution treatment and aging as well as to optimize special properties, such as fracture toughness, fatigue strength and high temperature creep strength.
Alpha and near-alpha alloys cannot be dramatically changed by heat treatment. Stress relief and annealing are the processes that can be employed for this class of titanium alloys. The heat treatment cycles for beta alloys differ significantly from those for the alpha and alpha-beta alloys.
Beta alloys can not only be stress relieved or annealed, but also can be solution treated and aged. The alpha-beta alloys are two-phase alloys, comprising both alpha and beta phases at room temperature. Phase compositions, sizes, and distributions of phases in alpha-beta alloys can be manipulated within certain limits by heat treatment, thus permitting tailoring of properties.
Description:
| Product Name | Polished ASTM B348 Titanium Alloy Bar For Chemical Processing / Medical Industry |
| Surface | Polished |
| Material | 99.60% Titanium |
| Grade | Gr1, Gr2,Gr5, Gr7, Gr9,Gr11,Gr12,etc |
| Standard | ASTM F136,ASTM F67 ,ASTM B348, ASTM B381, AMS 4928 |
| Technique | Hot forged , hot rolled , machining |
| Brand | FUTURE |
| Application | Industry,Aeroplane, Surgical plant |
Chemical Requirements :
| N | C | H | Fe | O | Al | V | Pa | Ti | |
| Gr 1 | 0.03 | 0.08 | 0.015 | 0.2 | 0.18 | bal | |||
| Gr 2 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | bal | |||
| Gr 3 | 0.05 | 0.08 | 0.015 | 0.3 | 0.35 | bal | |||
| Gr 4 | 0.05 | 0.08 | 0.015 | 0.5 | 0.4 | bal | |||
| Gr 5 | 0.05 | 0.08 | 0.015 | 0.4 | 0.2 | 5.5~6.75 | 3.5~4.5 | bal | |
| Gr 7 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | 0.12~0.25 | bal | ||
| Gr 9 | 0.03 | 0.08 | 0.015 | 0.25 | 0.15 | 2.5~3.5 | 2.0~3.0 | bal | |
| Gr 12 | 0.03 | 0.08 | 0.015 | 0.3 | 0.25 | bal |
Applications:
- Chemical processing
- Medical industry
- Marine industry
- Automotive parts
- nuclear industry
- construction industry
Specifications:
Our products as usual:Dia:6mm-350mm,6mm-400mm. Length:≤6000mm.We also support to customize as your require.
Advantages of titanium bar
- Low density and high strength
- Excellent corrosion resistance
- Good reisitance to effect of heat
- Excellent Bearing to cryogenic property
- Nonmagnetic and Non-toxic
- Good thermal properties
- Low modulus of elasticity
Advantages of our company
We have more than ten years of experience in building titanium’s factory,which includes almost one thousand employees.our factory located in baoji,titanium valley.we strictly control every process of production and strive to provide customers with high quality products,And our products sale to all over the world.
