JIS Titanium Metal Rod ASTM F136 Hollow Titanium Rods For Mechanical
Grade 2 5 Titanium Alloy Bar For Mechanical Equipment , Electroplating Equipment
Advantages
1. First-class technonlgy and the rigorous work attitude
2. We have the most professional team to solve all kinds of the problems you have during the
manufacturing process and provide your pressure vessel drawing for free if you need.
3. Low purchasing cost for repetitive orders in the long-run as our performance/price ratio is higher.
4. Never be backorder.
5. Excellent customer service policies on repair/exchange/refund.
6. Serving both domestic and overseas customers with various requirements for Many years.
Titanium Alloy Bar Advantage:
- Good reisitance to effect of heat
- Excellent Bearing to cryogenic property
- Nonmagnetic and Non-toxic
- Good thermal properties
- Low modulus of elasticity
Titanium Alloy Bar Description:
| Product name | Grade 2 5 Titanium Alloy Bar For Mechanical Equipment , Electroplating Equipment |
| Titanium Type | Titanium alloy |
| Standard | ASTM B348, ASTMF67, ASTM F136, AMS4928, JIS etc |
| Grade | Gr1 Gr2 Gr5 Gr7 Gr9 Gr12 Gr23 |
| Length | Max6000mm |
| Diameter | 5-350mm |
| Technique | Forging ,Machining |
| Surface | Acid surface or polishing, sand blasted surface |
| Shape | Round, flat, square, hexagonal |
| Application | medical, chemical, aerospace, etc. |
Chemical Requirements
| Grade | Chemical Composition (<%) | ||||||||
| Ti | Al | V | Fe | C | N | H | O | Other max | |
| Gr1 | Blance | --- | --- | 0.2 | 0.08 | 0.03 | 0.01 | 0.18 | 0.4 |
| Gr2 | Blance | --- | --- | 0.3 | 0.08 | 0.03 | 0.01 | 0.25 | 0.4 |
| Gr3 | Blance | --- | --- | 0.3 | 0.08 | 0.05 | 0.01 | 0.35 | 0.4 |
| Gr4 | Blance | --- | --- | 0.5 | 0.08 | 0.05 | 0.01 | 0.4 | 0.4 |
| Gr5 | Blance | 5.5-6.75 | 3.5-4.5 | 0.4 | 0.08 | 0.05 | 0.01 | 0.2 | 0.4 |
| Gr7 | Blance | --- | --- | 0.3 | 0.08 | 0.03 | 0.01 | 0.25 | 0.4 |
| Gr9 | Blance | 2.5-3.5 | 2.0-3.0 | 0.25 | 0.08 | 0.03 | 0.01 | 0.15 | 0.4 |
