LC/APC ST/UPC Single Mode G657A1 2x4 Optical Plc Splitter

Price Negotiable

Price: Negotiable

MOQ: 10pcs

Delivery Time: 5~8 business days

Brand: UNIFIBER

Product Description

2x4 optical plc splitter mini steel tube LC/APC single mode G657A1 900um loose tube 1M

PLC Splitter means planar light-wave circuit splitter, which is based on planar light wave technology,Our 1xN,2XN PLC splitter with superior environmental and mechanical characteristics, widely used in FTTX,EPOM,BPON,GPON

APPLICATION

FTTX Systems
PON Networks

CATV
Optical Signal Distribution

FEATURES

Compact Design

Wide Operating Wavelength: From 1260nm to 1650nm
High Reliability and Stability

Low Insertion loss and PDL
Good channel-to-channel uniformity

Specification

Parameters	1×2	1×4	1×8	1×16	1×32	1×64	1×128
Operating wavelength	1260 ~1650nm
Insertion Loss (dB)(P/S Grade)	3.6/4.0	7.2/7.4	10.2/10.5	13.5/13.7	16.2/16.7	20.5/21	23.8/24.5
uniformity (dB)	0.4	0.6	0.8	1.0	1.2	1.8	2.0
PDL (dB)	0.2	0.2	0.3	0.3	0.3	0.4	0.5
Return Loss (dB)	≥55
Directivity (dB)	≥55
TDL(dB)	0.5
Operating/Storage Temperature (℃)	-40~85

Specifications (2XN):

Parameters	2×2	2×4	2×8	2×16	2×32	2×64		2×128
Operating wavelength	1260 ~1650nm
Insertion Loss (dB)(P/S Grade)	3.8/4.2	7.5/7.8	10.7/11	14/14.2	17/17.5		21/21.5	25/25.5
uniformity (dB)	0.6	1.0	1.2	1.5	1.8		2.0	2.5
PDL (dB)	0.2	0.2	0.3	0.3	0.3		0.4	0.4
Return Loss (dB)	≥55
Directivity (dB)	≥55
TDL (dB)	0.5
Operating/Storage Temperature (℃)	-40~85
Note: All the data above does not include connector
