Aluminium Profile Sheet Metal Roll Forming Machines Cutter Material Cr12 Heat Treatment
profile sheet metal roll forming machine for aluminium roofing china manufacturer
1. Company information
We manufacture wide range products of metal sheet cold roll forming machines as follows: 1) for Metal Building Industry/PEB (Pre-Engineering Building): HAYES style quick change CZ purlin machine(including automatic and quick-change type C purlin machine and Z purlin machine), light gauge steel framing machine(LGSF, Howick and SCOTTSDALE style), roof panel forming machine, corrugated panel roll forming machine, curving machine, glazed tile roll forming machine, floor decking machine, ridge cap roll forming machine, cladding facade system forming machine, cut-to-length slitting line etc., as well as some hydraulic shearing machine, hydraulic folding machine for gutter and flashing, etc.
2. Technical parameters:
| configurations | manual decoiler, main machine of roll forming, cutting device, output table, electric motor, PLC control system | ||||
| Material | processing material | Colored Steel plate, Galvanized Board, Aluminum Plate | |||
| thickness | 0.3mm-0.8mm | ||||
| Efficienty width | 1000mm | ||||
| Coil width | 1200mm | ||||
| Manual decoiler | The maximum load capacity:5 ton | Expand by band | |||
| The coil inside diameter:450-550mm | |||||
| Suitable Coil width:1250mm | |||||
| Main Forming machine | Forming steps | 13steps | |||
| Shaft diameter | 70 mm | ||||
| Thick of arch frame | 16mm | ||||
| Frame body | High strength steel pipe weld with color steel sheet cover | ||||
| roller material | 45# steel | ||||
| shaft material | 45# steel | ||||
| cutter material | Cr12 mold steel with quenched treatment | ||||
| Transmission | By 1” chain | ||||
| Work speed | 20-25m/min | ||||
| Hydraulic system | Automatic hydraulic cutting after forming, without wasting. | ||||
| Control Device |
PLC control touch screen Program language: English/Chinese(or as required) |
||||
| Operating mode | Button+touch screen | ||||
| Total power | 4 kw | ||||
| Main body color | Blue and orange(or as required) | ||||
| Voltage | 380v/50hz/3ph(or as required) | ||||
A. If buyers visit our factory and check the machine, we will teach you how to install and use the machine,
and also trainyour workers/technician face to face.
B. Without visiting, we will send you user manual and video to teach you to install and operate.
C. If buyer needs our technician to go to your local factory, please arrange board and lodging and other necessary things.
5. After service
A. One year guarantee for whole machine.
B. 24 hours technical support by email or phone call.
C. If there is any problem found of the machine, we will repair it for free in one year.
