Customizable Roller Shutter Door Roll Forming Machine Steel Sheet Slat
Customizable Roller Shutter Door Roll Forming Machine Steel Sheet Slat
Machine description
Machines rolling shutter door for post, base and Roll-up door.
A roller shutter, coiling door, roller door or sectional overhead door is a type of door or window shutter consisting of many horizontal slats (or sometimes bars or web systems) hinged together. The door is raised to open it and lowered to close it.
rolling shutter door machine consist of manual decoiler, forming machine with post cut, hydraulic staion, plc controller, run out table
PLC control system, Shutter Door Forming Machines automatically work.
Machine parameters
| Suitable Material | Material | Galvanized Sheet |
| Width | 152 mm | |
| Thickness | 0.7-0.8 mm | |
| Material of rollers | High grade 45# forged steel, surface hard chromium plating | |
| Rows of rollers | 12 stations | |
| Material of shafts | High grade 45# forged steel | |
| Diameter of shafts | 50mm | |
| Material of blade | Cr12 Heat Treatment | |
| Speed | 8-12 m/min | |
| Total power | 4 kw | |
| Voltage | 380V 50HZ 3Phase | |
| Appearance size (About) | 4600mm*800mm*1500mm | |
| Electronic control system | PLC +Touch Screen | |
Main Features
●Manual Decoiler can bear 2 tons
●Feeding platform
●Main molding core
●Hydraulic system
●Automatic shearing system
●Computer control system
●High-precision automatic counter
●Driven system protective covering
●Panel supporting table
FAQ
Q1: Are you a manufacturer?
A1:Yes, we are professional manufacturer of the roll forming machine
Q2. What are the main key points for selecting right machines?
A2: Whole structure,Roller Shaft,Roller Material,Motor&Pump,and Control system. As the new buyer, please kindly know that price not the final point.
Good quality is for long-term business cooperation.
Q3. Can you provide OEM service for roll forming machine?
A3: Yes, most of cold roll forming machine need to be customized as detailed request, because raw material , size , production usage, machine speed, then machine specification will be some different.
Q4. How about the after-sale service?
A4: We provide 5 years free warranty and free technical support for the whole life of any machine. During warranty period, if parts still broken, we can send the new ones freely.
Q5:I do not know about the machine and do not know how to install it. Can you install the machine in my factory?
A5: If you need us to send engineers to your factory, you will pay for the travel expense such as visa, round tickets, hotel, food Salary of 100 USD per day per person (from departure from our factory, until we are back to our factory). You also need to take care of his safety.
Q6: I receive a lot of quotations, they are big range, How could i choose?
A6: I have many easy ways to solve it. Fox example, I can teach you how to find the Traders out. Just contact me. It is free for contacting with me.
Q7: I have not whatsapp and skype, how could I contact with you?
A7: Send me one inquiry in the end of this page. Leave your contact information for me. I will contact you. It is free.
Q8. If I am in Beijing,Shanghai or Guangzhou,how to visit your company?
A8: 1) Beiing South Statioin to Cangzhou West Station (by fast train 1 hour).
2) Shanghai Hongqiao to Cangzhou West (4.5 hours)
3) Guangzhou Airport to Tianjin ,then Tianjin to Cangzhou West
When you arrive our station, we will arrange to pick up you there!
