Forte Lithium Thionyl Battery 400mA ER341245S Lithium Primary Cell
3.6V Cylindrical Lithium Battery ER341245S Non-rechargeable Battery for Flow Meters, TPMS
Forte offered the high temperature Li-SOCL2 batteries. Those batteries use different material and technique which are different from the standard batteries. High temperature batteries used special steel container and cover with high temperature structure, so Forte high temperature batteries don't have discharge, drum bulge & bottom, explosion, burning phenomenon problem. It's a safety power solution.
Feature
-
Higer & stable working voltage.
-
Nominal voltage is 3.0V, 90% capacity output under the stable voltage.
-
Widely using temperature range, can be operated in -60°C ~ +150°C.
-
Excellent storage life and reliability.
-
With low self-discharge, yearly self-discharge rate ≤ 1%, stainless steel container and hermetically glass-to-metal sealing structure to make sure the battery could be stored more than 10 years in the room temperature.
- Forte batteries are environmentally friendly and pollutant fee power, it's W/O mercury,cadmium,lead and other heavy metals.
Specification of ER341245S
| Nominal Capacity | 25000mAh |
| Nominal Voltage | 3.6V |
| Max. Constant Current | 400mA |
| Max. Pulse Current | 800mA |
| Weight | 220g |
| Volume | φ35.2*125mm |
| Workable Temperature | -60°C~+85°C |
Application
- Petroleum Industry: downhole high temperature EPG, flow meters,
- LWD/MWD and other downhole high temperature instruments(processing and battery racks can be done as required)
- Automobile Industry: TPMS, diesel engine cylinder monitors and so on
- Geothermy Industry: High temperature inspection instrument
- Military uses and other battery-powered devices used in high temperature
Product List
| Model | Size |
Nominal Voltage (V) |
Nominal Capacity (mAh) |
Max. Continuous Current (mA) |
Max. Pulse Current (mA) |
Operation Temperature |
Dimension (mm) |
Weight (g) |
Data Sheet |
| ER14250S | 1/2AA | 3.6 | 680 | 50 | 100 | -60°C~150°C | φ15.2*25.6 | 11 | |
| ER14505S | AA | 3.6 | 2000 | 100 | 200 | -60°C~150°C | φ15.2*50.5 | 20 | |
| ER18505S | A | 3.6 | 2200 | 150 | 200 | -60°C~150°C | φ19.5*51.5 | 34 | |
| ER26500S | C | 3.6 | 6000 | 150 | 300 | -60°C~150°C | φ27.2*50 | 55 | |
| ER34615S | D | 3.6 | 13000 | 100 | 200 | -60°C~150°C | φ35.2*61.5 | 105 | |
| ER261020S | CC | 3.6 | 13000 | 200 | 400 | -60°C~150°C | φ26.8*100 | 102 | |
| ER341245S | DD | 3.6 | 25000 | 400 | 800 | -60°C~150°C | φ35.2*125 | 220 |
Important Notes:
Do not short or charge the battery.
Over-discharging, crushing, incinerating, and disassembling the battery are prohibited.
Do not heat / use the battery beyond the permitted temperature range.
