Home HDMI 2.0 4K Hdmi Distribution Amplifier 1x4 Up To 4 Outputs Metal Housing
HDMI 2.0 4K 1 x 4 HDMI Distribution Amplifier Splitter Up to 4 Outputs
Hangalaxy this kind of HDMI Switch with Optica/Coaxial/3.5mm Audio Out, 4 Port 4 x 1 Switcher Selector with IR Wireless Remote Control, 4K@60Hz, HDMI2.0 HDCP 1.4, Support DTS-HD/Dolby-TrueHD/DTS/Dolby-AC3/ DSD. This 1x4 HDMI splitter distributes 1 HDMI source to 4 HDMI displays simultaneously. Apply for STB, DVD, Media Player, Laptop, D-VHS and other HD-Player devices. It's compatible with HDMI 3D and 4Kx2K.
Key Characteristic
1. Connects up to 4 HDMI displays at the same time from a digital video source.
2. Support up to 3D, 4K 30Hz 4:4:4, 12-Bit deep color.
3. Built in EDID learning/integration function.
4. Support LPCM 7.1,Dolby TrueHD,DTS-HD Master Audio.
5. Bandwidth: 25~340 Mhz.
6. HDMI 1.4a compliance, HDCP 1.4 complaint.
7. DVI 1.0 compliance.
Application
Support configures the video resolution automatically according to the capabilities of each connected monitor, allows simultaneous mixed 4K and 1080p display outputs.
Specification
| Video Input | |
| Interfaces | 1 x HDMI Type A Female (Black) |
| Impedance | 100Ώ |
| Max. Distance | 1.8m / 4K@60Hz (4:4:4) |
| Video Output | |
| Interfaces | 4 x HDMI Type A Female (Black) |
| Impedance | 100Ώ |
| Max. Distance | 1.8m / 4K@60Hz (4:4:4) |
| Video | |
| Max. Data Rate | 18Gpbs (6 Gbps Per Lane) |
| Max. Pixel Clock | 600 MHz |
| Compliance | HDMI (3D, Deep Color, 4K); HDCP Compatible |
| Max. Resolution | Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4) |
| Audio | |
| Input | 1 x HDMI Type A Female (Black) |
| Output | 4 x HDMI Type A Female (Black) |
| Connectors | |
| Power | 1 x DC Jack |
| Power Consumption | DC5V:4.84W:23BTU |
| Physical Properties | |
| Housing | Metal |
| Weight | 0.48 kg ( 1.06 lb ) |
| Dimensions (L x W x H) | 20.00 x 8.00 x 2.50cm (7.87 x 3.15 x 0.98 in.) |
Ideal Application
Hangalaxy Exhibition Activities
Package
UHD 1x4 HDMI Splitter: 1PC
5V2A DC Power adapter: 1PC
Operation Manual: 1PC
Note
For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
