Household Grade A BYD Blade Cell LiFePO4 Energy Storage Battery 51.2V Low Voltage

Price Negotiable

Price: Negotiate

MOQ: 1 unit

Delivery Time: 5-8 working days bulk order negotiate

Brand: Fenigal

Product Description

Household LiFePO4 Energy Storage Battery Grade A BYD blade cell 51.2V Low Voltage Battery
FNE single phase hybrid solar Inverter series can convert solar energy to AC energy and store energy into battery. Worked with 48V battery both lead-acid and lithium type, the PV hybrid inverter has multiple application modes such as self-consume, peak shaving and valley filling, and backup power supply. The operating mode of hybrid inverter solar system depends on photovoltaic energy and user preferences. In addition, It supports parallel connection of multiple machines and is suitable for Hybrid energy storage solar system.

Flexible configuration

Scalable battery design for easy expansion
Max. 6pcs in parallel

Safe and reliable

BYD blade lithium cell
More Safety, longer life cycle and more usable energy
Upto to more than 10 years working life

Convenient operation and maintenance

Stylish, ultra-thin
Easy connection,saving installation time and cost

Abundant configuration

Compatible to residential 48V hybrid inverter
and off grid inverter
Compatible with CAN / RS485 communication interface.
Matching with leading inverter brands

Benefit

● BYD original blade battery cell
● BYD original battery PACK module
● BYD original BMS/BMU/BCMU
● BYD original structure design
● BYD original technical solutions
● BYD original sales record

Model	SNE5126LFP-BL
Performance
Battery type	BYD Blade Lithium-iron Phosphate (LiFePO4)
Battery energy(KWH)	6.144KWH
Nominal Capacity(AH)	120AH
Nominal Voltage(V)	51.2V
Operating Voltage Range(V)	43.2V-57.6V
Standard charging mode	Constant current charging (CC)
Standard charging current(A)	30A @ 25°C
Max. constant charging current(A)	120A @ 25°C
Charge limit voltage(V)	60.8V
Standard discharging mode	Costant current discharging(CC)
Standard discharging current(A)	30A @ 25°C
Max. discharging current(A)	120A @ 25°C
Discharging cut-off voltage	32V
Scalability	Max.6 strings in parallel
Depth of discharge (DOD)	80％
Design life	＞10 years(25°C/77F)
Compatible hybrid inverters	SNE5K-D1/SNE6K-D1/SNE8K-D1SNE8K-DA
Protection function
Protection	Over-temperature, over charge, under-voltage, over-current, short circuit alarm Function
Display and Communication
Display	LED indicator
Communication	CAN/RS485
General Spacification
Dimension(HWD)	1112443118MM
Weight	About 46KG
Installation	Wall Mount
Shipping status SOC	20%~30%
Charging Temperature	-20~ +55°C
Discharging Temperature	-30~ +60°C
Short term storage ambient temperature	-20~+35°C ( <3 months,20~60% SOC)
Long term storage ambient temperature	-20~+30°C ( <1 year,30~60% SOC)
Max. operating altitude	4,000m(Derating above 2,000m)
Protection degree	IP21, indoor installation
Relative humidity	5%-95%
Cooling	Natural cooling
Noise emission	＜29db
Certificate	CE, UN38.3, UL
