HC-KFS053B Mitsubishi AC SERVO MOTOR 50W 51V 0.9V NEW

HC-KFS053B Mitsubishi AC SERVO MOTOR 50W 51V 0.9V NEW

Specifications

Primary brand
Mitsubishi Electric

Main function
AC servo motor

Product series / family name
MELSERVO J2S series

Sub-range name
HC-KF series

Functions
AC brushless rotary servo motor

Design
straight shaft
built-in e/m brake
built-in absolute feedback encod. (17-bit)
low inertia / small power capacity
fan cooling

Supply voltage (AC)
200Vac class

Rated current
0.83A

Rated active power (kW)
50W / 0.05kW

Rotational speed
3000rpm
4500rpm (maximum)

Torque
0.16Nm nominal

Maximum torque
0.48Nm

Moment of inertia
0.0000056kg.m2 (0.056kg.cm2)

Mounting mode
40x40mm flange mounting

Resolution
17-bit (equivalent to 131072ppr) feedback

Degree of protection
IP55

Dimensions
H55.7mm x W42mm x D134.5mm

Net Height (mm)
55.7 mm

Net Width (mm)
42 mm

Net Depth (mm)
134.5 mm

Ambient air temperature for operation
0...+40 °C

Ambient air temperature for storage
-15°C...+70 °C

Maximum current
2.2 A

Order code / Manufacturer SKU
HC-KFS053B
