3 Phase SGDB 1AADGY68 900W Yaskawa Industrial Servo Drives 10 AMP

3 Phase SGDB-1AADGY68 10 AMP Industrial Servo Drives AC 230V Input

Quick Details:

• YASKAWA ELECTRIC

• SGDB-1AADGY68
• SERVO DRIVE
• 200-230VAC
• 50/60HZ
• 3PHASE
• 10AMP

• One Year Warranty


SGDB Series SERVOPACK
The operation of the SGDB SERVOPACK is basedon commands sent via serial communications or contacts.

Information of motor position is managed within the SERVO-PACK, and there is no need to form a speed or position feedback loop between

the host controller and SERVOPACK.
Furthermore, acceleration and deceleration patterns can also be created based on user settings within the SERVOPACK.

Using the SGDB SERVOPACK
Operation Modes
The SGDB SERVOPACK has four operation modes.

These modes can be switched at any time by means of a contact.

Automatic Mode
Following the input of command position data, the input of an operation start signal performs
the positioning based on the input data.
The operation method in automaticmode canbe selectedfrom thefollowing: Stationnumbers,
digital switches, serial communications, and command table.

Manual Mode
The Servomotor runs at a constant speed while a manual mode signal is being input.

Pulse Mode
Positioning is performed by a pulse train command from an external pulse generator.

1. Pulse system: Line driver, line receiver

2. Pulse form: Two-phase pulse trains with 90° phase difference (×1) (450 kpps max.)
                       Sign + pulse train (450 kpps max.)
                       CW + CCW pulse trains (450 kpps max.)

An external PG input is triggered when an /LPG signal is input.
