1.5 CBM Self Loading Concrete Mixer Multifunctional Machinery CE Certificate
Price:
Negotiable
MOQ:
1 sets
Delivery Time:
5 days after we got advanced payment
Brand:
Cinacharm
Product Description
1.5 CBM self loading mobile concrete mixer with High Quality self loading double cone concrete drum mixer with lift
Product Application
SFM1500 Self Loading Concrete Mixer Truck is a kind of multifunctional machinery which combines the transit mixer, concrete mixer and wheel loader together. It can automatically load, measure, mix and discharge concrete mixture. Equipped with powerful YUNNEI ,55 kW Diesel engine and 4 wheel drive plus 2 wheel steering, the self loading concrete mixer is just like a truck and the operator can drive it to where it needs to go. It is very convenient for loading material, such as cement, aggregate, stone.
The Geometric Volume of Mixing Drum is 2.3CBM. Concrete output is 0.8 CBM per Batch. The wide cabin windscreen and the specially designed loading arms dramatically improve visibility during casting operations. This high-productivity self loading concrete mixer is price-worth, easy to use, features excellent daily performance and reliability.|
SPECIFICATIONS FOR JZC350DH DIESEL HYDRAULIC CONCRETE MIXER
|
|||
|
Main performance parameters
|
Geometric Volume
|
Liter
|
2300
|
|
Unmixed Capacity
|
Liter
|
1500
|
|
|
Mixed Capacity(OutPut)
|
Liter
|
1200
|
|
|
Self Loading Shovel Capacity
|
Liter
|
300
|
|
|
Productivity
|
m³/h
|
16-24
|
|
|
Bags of Cement per Batch
|
bag
|
8(50kg/bag)
|
|
|
Max.Size of Aggregate
|
mm
|
60
|
|
|
Drum Thickness
|
mm
|
6
|
|
|
Engine
|
Engine brand
|
|
YUNNEI (China Top Brand)
|
|
Engine Model
|
|
YN27GBZ (490GBZ)
|
|
|
Type
|
|
4-Cylinder, 4-Stroke, In-line, Turbo-Charged and Water-cooled
|
|
|
Rated Rotating Speed
|
RPM
|
2200
|
|
|
Displacement
|
L
|
2.7
|
|
|
Power
|
Hp
|
Power: 55 KW ( 75 HP),
|
|
|
Emission Standard
|
|
Euro II
|
|
|
Chassis
|
Structure
|
|
Articulated Structure
|
|
Drive Type
|
|
Drive Type
|
|
|
Transmission
|
|
2 Forward +2 Reverse Shift (Low+ High Speed)
|
|
|
Brake Type
|
|
Gas Cap Oil
|
|
|
Gearbox Mode
|
|
Counter Shaft, Power-shift
|
|
|
Tyre Size
|
|
12-16.5
|
|
|
Vehicle
|
Drum and Shovel Control
|
|
By Joystick
|
|
Driver's Cab
|
|
Fan or Air-conditioner
|
|
|
Max. Drive Speed
|
KM/H
|
30
|
|
|
Grade Ability
|
%
|
30
|
|
|
Operating Weight
|
kg
|
5200
|
|
|
Overall Size
|
mm
|
6750×2300×2450
|
|
