Fixed Lift Hopper Dry Mix Skip Type Stationary Concrete Batching Plant Price stationary concrete batching plant
Fixed Lift Hopper Dry Mix Skip Type Stationary Concrete Batching Plant Price stationary concrete batching plant
Model: JS750
Charging capacity: 1200L
Discharging capacity: 750L
Mixing Motor power: 22kw
Lifting Motor power: 7.5kw
Pump Motor power:2.2kw
Mixer arm materials: High Manganese Steel
Discharging way: Pneumatic
Water dispenser Qty.: 1 unit
Lubricating system: 1 unit
Underframe+support legs+walking platform+ladder+guardrail: 1 unit
| Model | HZS35 |
| Place of origin | Zhengzhou, China |
| Size (length × width × height) | 5000*2500*2600 |
| Material | Steel Q235/Medium-manganese anti-wear ball iron |
| Colour | White, blue, yellow, red, gray, black, green, etc. |
| Payment method | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| MOQ | One set |
| Deliveryperiod | One week |
| Supply Capaciy | 20 sets / month |
| Port | Shanghai Port, Tianjin Port, Khorgos Port, Alashankou, Jimu Nai, Takshken, Gwadar, Pakistan, Tengchong, Yunnan, Dongxing Port, Guangxi. |
| Elevating Bucket Type HZS Concrete Batching Plant | ||||
| Modle | HZS25 | HZS35 | HZS50 | HZS75 |
| Theory productivity | 25m³/h | 35m³/h | 50m³/h | 75m³/h |
| Mixer model | JS500 | JS750 | JS1000 | JS1500 |
| Mixer discharge | 500L | 750L | 1000L | 1500L |
| Discharge height | 3.8m | 3.8m | 3.8m | 3.8m |
1. HZS series concrete batching plant is the equipment which own the features of material storage, weighing and mixing.
2. Whose advantage is good mixing quality, high productivity and so on, and it can mixing types of the concretes.
3. So it is the suitable equipment for the medium project construction like construction project,hydropower, roadway, sea port,
wharf.bridges,large scale prefabricated parts factory and concrete factory.
Q1: Are you trading company or manufacturer?
A: We are factory. We can design and manufacturer products with our own patent(Our patent is double shaft end seal)
Q2: How long is your delivery time?
A: Generally it is 3-7 days if the goods are in stock. or it is 5-15 days if the goods are not in stock, it is according to quantity.
Q3: What is your payment method?
A: 30% of total price should be paid by T/T as down payment; 70% balance payment should be paid by T/T before delivery. We also support L/C, Western Union.
Q4: How many types of concrete batching plant you have?
A:Two types. We have stationary concrete batching plant and mobile concrete batching plant.
Q5: What’s the capacity of concrete batching plant do you have?
A:The capacity of concrete batching plants range from 25m3/h to 240m3/h.
Q6: Is the belt conveyor necessary?
A: No. The discharging height of concrete batching plant is 1m. If your discharging height is higher, the belt conveyor is necessary. It can reach 3.5/3.8/4.0 meters.
Q7: Do you have CE certificate for your concrete batching plant / cement silo?
A: Yes, we have. Both are our patent products, certificated by CE, ISO, BV, SGS etc.
