stationary wet concrete batch plant 120m3 Large Capacity ready mixed Concrete Batching Plant HZS120
stationary wet concrete batch plant 120m3 Large Capacity ready mixed Concrete Batching Plant HZS120
120m3/h wet mix concrete batching plant is my company in view of the frequent mobile transitions of construction and development of concrete mixing equipment users.
The machine adopts the international popular quickly assembled module type structure, easy installation, compact and reasonable, cover an area smaller, higher automatic degree, widely used in bridge, construction in the country, water conservancy, electricity and other infrastructure construction.
A concrete batch mix plant has a number of parts and accessories that combine and work together to produce quality concrete. Some of the major components are as below:
Mixing unit
Control panel
Control panel will control the working of the machine. It is also possible to save and print mix material recipes in the latest equipment. Control panel assist in fast and accurate measurements of the ingredients. With growing demand for high quality and accurate concrete it becomes important to produce quality material without any wastage. This is where control panel helps to control all components of the batching plant.
Additive weighing scale
Batching machine
Feeding unit is one of the important component. There are batching machine to facilitate feeding of coarse aggregates and sand. It will hold different sized aggregates / sand into different hopper.
Charging conveyor / Skip
Charging conveyor or a skip is to carry the weighed aggregates to the mixing unit.
Cement silo is to hold large volumes of cement that comes in bulk trucks. It is usually provided with safety accessories. A screw conveyor of suitable diameter and length is at the bottom enabling transfer of cement into the cement weigh hopper. Many small capacity machines are equipped with a cement hopper. The opening of the hopper is big and it facilitates adding of cement that comes in bags. Bags have to be placed on top of the hopper and once they are torn, cement will fall into the hopper.
| Model | HZS120 |
| Rated Productivity | 120m3/h |
| Main Mixer | JS2000 double shaft concrete mixer/ Sicoma brand available |
| Max. Aggregate Diameter | 80mm |
| Capacity of Aggregate Bin | 4X16m3 with separate weighing system, |
| Aggregate Conveying Mode | Belt conveyor |
| Aggregate Weighing Precision | ±2% |
| Cement Weighing Precision | ±1% |
| Water Weighing Precision | ±1% |
| Additive Weighing Precision | ±1% |
| Total Weight | 118T |
| Discharging Height | 4.1m |
| Screw Conveyors | φ273mm |
