LSY 325 conveyor screw screw conveyor for silo cement

Screw Conveyer is the use of rotating screw within the casing materials will be transported along a fixed time and delivery work, head and tail bearing to the shell, sliding bearing is equipped with dust-proof sealing device for the suspension bearing, bearing bush generally use of powder metallurgy, transport cement adopts the felt pad, hoisting shaft and propeller shaft connected by sliding block.

The spiral pipe conveyor is welded with a continuous spiral blade in a cylindrical casing, and the casing rotates together with the spiral blade. Due to the centrifugal force and the frictional force, the added material rotates together and is lifted, and then slides along the spiral surface under the gravity of the material, so that the material rotates together with the spiral tube to realize the forward movement of the material, as if it is not rotating. The screw moves along the rotating nut for the purpose of conveying the material.

Application:

Applicable to various industries, such as building materials, chemical industry, electric power, coal, metallurgy,food and other industries, applicable to horizontal or oblique conveying powder, granulated and small lump materials, such as coal, ash, slag, cement, food, etc.

Mainly used to work with powdery storage tank like cement silo to transport powdery materials in prefabricated factories and all kinds of construction sites, roads, bridges, airports, tunnels and other projects.

Suitable to convey various dusty, grainy, small lumpy bulk materials such as clay powder, coal dust, sand, grain, small coal, cobbles and cast iron shavings, etc

Screw conveyor is an efficiency transportation equipment .

Screw shaft is made of several sections which connected with sp line.

With this special design, it can bear large load capacity and easy to dismounting.

Screw conveyor is special used for cement plant or transport powder in field working.

It is applicable for transporting powder granular and small blocked bulk material, such as clay powder, cement, concrete, sand, stone, grain, coal etc.

Also can complete the gathering, stirring, mixing, dehydrating, customizing material, unloading, stacking during conveyor.

♦ High-quality steel pipe with good integral rigidity.

♦ Standard parts and components, which makes it is convenient for transportation.

♦ Once-forming spiral double pitch paddles, which will never block the material.

♦ Double-pitch paddles, which decrease the compressed degree of material when being transported.
