Mobile Concrete Stabilized Soil Mixing Station With A Production Of 300t/H
Mobile Concrete Stabilized Soil Mixing Station With A Production Of 300t/h Dry Mix Stabilized Soil Mixing Stations
Stabilized soil mixing plant is a mixing machinery system that is used in the continuous production of highway sub-base material.
Its components include an aggregate supply measuring system, powder supply measuring system, water supply system, mixing device, storage device and control system.
Our stabilized soil mixing plant uses a double-horizontal-shaft continuous type mixer
and its productivity is 200-600t/h.
This key concrete equipment is special mixing plant for achieving the continuous even mixing of the variety of stabilized road base materials which has the high matching accuracy (in accordance with the requirements of raw materials), so it is widely used in the construction fields of road, airport, dock and other stabilized road base material construction project.
This station is with good work performance, reasonable structure, easily operated,high capacity,mixing uniformly,it is an ideal plant for stabilized soil.
| Items | Model | Model | Model | Model | Model | |
| Data | YWMCB300 | YWMCB400 | YMWCB500 | YMWCB600 | YMWCB800 | |
| Capacity | 300t/h | 400t/h | 500t/h | 600t/h | 800t/h | |
| Measuring Type |
Volume measuring Computer measuring |
|||||
| Speed Regulation |
VF Electro-Magnetic Manual Automatic |
|||||
| Control Mode | ||||||
| Weighing Accuracy | Aggregate | ±3%(volume),±2%(Electronic) | ||||
| Power material |
±2%(volume),±1%(Electronic)
|
|||||
| Water | ±1%-2% | |||||
| Total Power | 102.7kw | 120.2kw | 155.5kw | 170.5kw | 189kw | |
| Total Weight | 39t | 41t | 51t | 54t |
56t |
|
Questions:
1. Q: What is the productivity of concrete mixer and concrete batching plant?
A: The productivity of concrete mixer ranges from 6m3/h to 100m3/h.
The productivity of concrete batching plant ranges from 25m3/h to 180m3/h.
2. Q: Warranty period your company giving for PLC/MOTORS?
A: 12 months after installation.
3. Q: Operating system warranty and any extra unit giving with plant?
A: Operating system and any extra unit warranty: 12 months after installation
4. Q: Computer warranty?
A: 12 months after installation.
5. Q: Which port you will delivery?
A: Shanghai Port, Tianjin Port, Khorgos Port, Alashankou, Jimu Nai, Takshken, Gwadar, Pakistan, Tengchong, Yunnan, Dongxing Port, Guangxi.
6. Q:What's your payment terms?
A: L/C,D/A,D/P,T/T,Western Union,MoneyGram
7.Q: What's the material you will using?
A: Steel Q235/Medium-manganese anti-wear ball iron
