Concrete Screw Conveyor Machine And Free Spare Parts For Concrete Batching Plant Iso&Ce Approved
Lsy273 Screw Conveyor And Free Spare Parts Iso&Ce Approved Use For Concrete Batching Plant
Product description of screw conveyor:
New product steel incline grain sand cement spiral auger screw conveyor suppliers(also known as auger conveyor, screw conveyor, and spiral conveyor), is the main unit for mechanical transport operation of industry and agriculture, which uses motor to drive screw rotation and move material to achieve conveying purpose. Pipe screw conveyor is suitable for all industries such as building material, chemical industry, power industry, metallurgy, coal industry and grain industry, for horizontal or tilted transportation for powdery, granular and small lump materials, such as coal, dust, residue, cement and grain which their temperature is less than 200℃.
Product Advantage of screw conveyor:
1. High-speed conveyor: small diameter, high-speed, variable screw pitch design to ensure that products work smoothly and quickly, feed material on average.
2. Minimum site constraints: equipment shell made of high quality seamless steel pipe,Each segments connected by a flange as a whole, overall equipment rigidity,whether horizontal or large angle can be continuously fed, and directly connected to its supporting equipment fixed without the need of foundation, full use of space mobile, disassembly simply, easy and fast.
3. Reliable sealing: the equipment is lubrication, seal, reliable without leakage,neither the phenomenon of wasting materials, but also to create a good working environment.
4. A wide range of connection: inlet and discharge port may adopt universal joints,bag, flange connection, can also be connected with the valve, flapper valve combination.
5. Innovative design: Dahan mechanical screw conveyor for advanced and reasonable design, combined with advanced manufacturing processes and improve the quality assurance system, so that the specific volume is small, bearing torque, low noise, no oil leakage and other significant advantages.
|
Item
|
LSY273
|
|
Delivery distance
|
8m
|
|
Delivery angle
|
0-45°
|
|
MAX.productivity |
1-30t/h |
|
Shell pipe diameter
|
273mm
|
|
Motor power
|
18.5kw
|
We have different sizes and models of 165 /219/ 273 mm Diameter Cement Screw conveyor for your choice according to your requirement.
| Model | Screw diameter | Rotation speed | Output | Maximum length | Angle of inclination | Power | |
| L≤7m | L>7m | ||||||
| (mm) | (r/min) | (t/h) | (m) | (degree) | (kw) | ||
| LSY160 | 163 | 308 | 25 | 15 | 0°~60° | 5.5 | 7.5 |
| LSY200 | 185 | 260 | 40 | 18 | 7.5 | 11 | |
| LSY250 | 237 | 200 | 60 | 25 | 11 | 15 | |
| LSY300 | 285 | 170 | 90 | 25 | 18.5 | 22 | |
| LSY400 | 362 | 170 | 120 | 25 | 18.5 | 22 |
|
Features of screw conveyor
1.Large load capacity , safety and reliability ;
2.Well-adapted, convenient to install and maintain, long life;
3.Small size ,high rotation speed;
4.Flexible arrangement on position of inlet and outlet.
