Ready Mix Premixed 50m3/h Hzs50 Concrete Batching Plant Wet Mixing plant
Good quality hzs50 wet mixing ready mix premixed concrete batching plant
The configuration of HZS series mixing station has the characteristics of excellent stirring performance, accurate and stable measurement, high reliability, convenient maintenance and maintenance, and high environmental protection. The HZS concrete mixing plant is an automatic mixing function. The proposed mixing station consisting of a combination of a twin-shaft mixer and a batching machine can fully utilize the advantages of the batching machine and the mixer. The hopper concrete mixing plant saves between one-half and two-thirds of the site area compared to the usual oblique belt conveyor. It adopts modular structure and modular unit, which is very convenient for installation and relocation.
The concrete mixing station is composed of systems and structural components such as feeding, storage, batching, discharging and control. The use of concrete mixing stations for concentrated mixing of cement concrete has many advantages:
(1) The concentrated mixing of cement concrete facilitates strict control of concrete mix ratio, ensures the quality of concrete, and fundamentally changes the inaccurate situation of scattered mixing ingredients on site;
(2) The concentrated agitation of cement concrete is conducive to the use of automation technology, which can greatly improve labor productivity, save labor and reduce costs;
(3) It is not necessary to install mixing equipment on the construction site, stack sand and gravel materials, and store cement, which saves the site and avoids waste of raw materials.
| Model | HZS50 |
| Rated Productivity | 50 m3/h |
| Mixer Capacity | 1m3 per batch |
| Main Mixer | JS1000 double shaft concrete mixer |
| Power of Main Mixer | 52KW |
| Max. Aggregate Diameter | 80mm |
| Feeding Mode | Lift Hopper |
| Batching Unit | PLD1600-3 bins |
| Measuring Scope & Accuracy of Aggregate | ±2% |
| Measuring Scope & Accuracy of Cement | ±1% |
| Measuring Scope & Accuracy of Water | ±1% |
| Additive Weighing Precision | ±1% |
The concrete mixing station not only has an excellent mixing machine, but also has a variety of sophisticated accessories, such as screw conveyors, metering sensors, pneumatic components, etc. These components ensure the high reliability of the concrete mixing station during operation, accurate measurement skills and Extremely long service life. At the same time, each maintenance and repair part of the concrete mixing station is equipped with a walking platform or a check ladder, and has sufficient control space. The mixing host can be equipped with a high-pressure automatic cleaning system, which has the functions of lack of oil and over-temperature automatic alarm function, which is convenient for equipment maintenance.
