HZS180 Ready Mix Concrete Batching Plant Portable Types Wet Mix Product

Price Negotiable
Price: Negotiable
MOQ: 1 set
Delivery Time: We can delivery the goods within 15 days
Brand: Cina Charm
Product Description

HZS180 Ready Mix Concrete Batching Plant Portable Types Of Batching Plants Wet Mix Product

Brief introduction of Concrete Batching Mixer Plant Hzs180:

HZS180 concrete mixing plant overall uses the integrated steel casting, high-quality H-beam, not only easy to install, but also enhance the overall structural strength of concrete mixing station, and, it can be applied to a variety of complex terrain structure.

HZS concrete batching plant is also called concrete mixing plant, concrete mixing station. It includes horizontal twin shaft compulsory concrete mixer, concrete batching machine, cement silo and screw conveyor, belt conveyor or skip hopper, and control room. It can produce a variety of concretes, such as plastic, dry hard concrete with high production efficiency, short mixing time, and easy operation. HZS concrete batching plant is widely used in large and medium-sized building construction, road and bridge, and precast plants. It is the idea plant to for the production of commercial concrete.

Concrete Batching Mixer Plant Hzs180 of Main Features:1) According to the requirements of the construction and work site demand,provides enough choice for a variety of mixing building and mixing station structure.
2) The modular structure is convenient and efficient for installing and removing.
3) High output,fast speed and stable performance.
4) The core parts adopt internatonal famous brand with reliable quality.
5) The humanized design provide simple and convenient operation.

concrete batching plant parameters:

Model
HZS180
Rated Productivity
180m3/h
Main mixer
JS3000
Max.Aggregate Diameter
80mm
Feeding Mode
belt
Batching Unit
PLD4800
Measuring Scope&Accuracy of Aggregate
4000±2%
Measuring Scope&Accuracy of Cement
1500±1%
Measursing Scope&Accuracy of Water
1000±1%


100±1%



concrete batching plant advantage

Changli manufactured concrete batching plant use JS series mixer. JS3000 make sure each batch produce 3.0m3 of concrete with sufficient space for mixing. JS series mixer is designed to operate with a high mixing performance even for the most challenging applications. These mixers are preferred for producing precast concrete such as low or zero slump precast concrete, fiber reinforced concrete, self-compacting concrete,etc. They provide the highest homogeneous mixture even with shorter mixing times.

Advanced features of Changli--CINA CHARM JS series concrete mixer: --High mixing performance even for challenging concrete applications
--High mixture homogeneity with short mixing times
--High wear-resistant mixer wear parts
--Easy maintenance due to wide maintenance gates and bolted type replaceable linings
--Heavy duty gearbox
--Low maintenance cost
