HZS120 Ready Mix Concrete Batching Plant 120m3/H Stationary Wet Batch Concrete Plant
Batching plant ready mix concrete plant HZS120 120m3/h stationary wet concrete batch
Production description of HZS120 ready mix concrete plant
HZS120 belt type concrete mixing plant is an automatic equipment of concrete mixing system, which consists of five major systems such as material weighing system, mixing system, electrical control system and powder storage and transportation system. It has high-precision and high-efficiency computer control system, separate manual control, material ratio control, automatic falling material compensation, printing system, and can automatically complete the production scheduling time of storage tank. Shape display equipment according to the site conditions.
High mixing quality, high efficiency, low power consumption, low noise, and simple operation.
The components of HZS120 ready mix concrete plant
1. Aggregate storage, dosing and transportation systems.
2. Powder storage, dosing and transportation systems.
3. Water supply, dosing and drainage systems.
4. Additive storage, supply and dosing systems.
5. Aggregate compacting systems.
6. Mixing and dust removal system.
7. Main structure of the tower.
8. Pneumatic system.
9. Electrical control system.
Parameters of HZS120 ready mix concrete plant
| Technical parameters | Unit | HZS120 | |
| Theory prouducivity | m³/h | 120 | |
| Volume of mainframe | m³ | 2 | |
| Batcher | PLD3200QD-IV | ||
| Batcher(volume perbin) | m³ | 20 | |
| Batcher(bin's amout) | 4 | ||
| Aggregate max scale | kg | 4×2000 | |
| Cement max scale | kg | 1200 | |
| Powder material max scale | kg | 400 | |
| Water max scale | kg | 500 | |
| Liquid additive max scale | kg | 50 | |
| The mixer's power | kw | 2×37 | |
| Lifting power | kw | 30 | |
| Whole power | kw | 150 | |
| Discharging height | m | 3.8 | |
| The whole weight | t | 60 | |
| Dimension(length×witch×height) | m | 46.7×23×20 | |
| Feeding style | Belt | ||
| Calcuulating precision | Aggregate | ±2% | |
| Powder material | ±1% | ||
| Water | ±1% | ||
| Additives | ±1% |
||
Our services:
Installation.
1. Two engineers are required for installation.
2. The customer pays the engineer a subsidy of $80 per person per day.
3. The customer shall bear the visa application fee and round-trip air ticket of the engineer; Board and lodging.
4. The Seller shall provide basic drawings, electrical diagrams and manuals.
5. Installation usually takes 30 working days (but also depends on local human and material resources).
FAQ
Question 1: What is the function of concrete mixing plant?
A: It is used to produce various kinds of concrete to meet the construction projects of buildings, bridges, docks, airports, railroads, etc.
Question two. How to choose the right model of intermittent plant?
Answer: Please tell us the capacity of concrete you want to produce per hour or per month (m3/h, t/h).
Question 3: What is the paymet term you use?
Answer: usually the most common in the world such as wire transfer, letter of credit
