Outdoor IP65 1920Hz Stadium Perimeter LED Display
SMD Stadium LED Display Outdoor , IP65 Led Perimeter Display for Sports Events
Product Description
1)IP65 weatherproof standard,against harsh environment such as water, dust , and grass clippings;
2)Convenient installation and software setup.No need to number the cabinets;
3)Easy power and data connections, daisy chain used from one cabinet to the next for quick connection;
4)High refresh rate : ≥1200 Hz( Photos taking with no flickers )
5)Cabinet angle adjusted freely 60 ~ 90 degrees enhance viewers’ visual enjoyment
6)Excellent flatness between cabinets, with claw lock system to link the cabinets;
7)Impact resistance. Soft rubber mask facia to protect the screen from the players' impact and protect the players themselves;140°Viewing Angle- SMD lamps provide wider viewing angle both vertically and horizontally
Product specification:
| Usage: | Outdoor Football Stadium | Tube Chip Color: | Full Color |
| Pixel Pitch: | 10mm | Pixel Density: | 10000dots/㎡ |
| LED Model: | SMD3535 | Lifespan: | 100,000hours |
| Display Function: | Video,Photo,Live Video | Weight Of Cabinet: | 61kg/sqm |
| Module Size: | 320x160mm | Brightness: | ≥7000cd/㎡ |
| Cabinet Size: | 960x960mm/1280*960mm | Power Supply: | Meanwell |
| Input Voltage: | AC110-220V±10%,50/60Hz | Cabinet Material: | Steel or Die-casting Aluminum |
| Output Voltage: | DC-5V,40A/60A/80A | Working temperature: | ~30℃~50℃ |
| Control Mode: | Synchronous /Asynchronous | Control Card: | Sending Card and Receiving Card |
Stadium perimeter LED display's Advantages:
1. Soft mask: We have our own design for soft mask. For one thing, this can protect players and for
another, it can also protect LED panel.
2. Soft rubber protector on the top of cabinet: We will put a soft rubber protector on the top of each cabinet to protect players
3. Adjustable angle: There is supporter at the back of cabinet. So the view angle can be adjusted accordingly.
4. Good waterproof protection: Front is IP65 and back is IP65. There is totally no problem for outdoor application.
5. Big view angle: SMD view angle is bigger than DIP.Its view angle is 160°for horizontal and 110°for vertical.
6. Good color uniformity: Since 3 LED chips are encapsulated in one lamp, SMD color uniformity is much better than DIP so the showing effect is perfect.
7. Energy saving: power consumption is a key factor for LED billboard. BAKO’s LED display is designed with low power consumption to help clients to save energy.
8. Double protection for data transmission: We will make double protection for data transmission. Even if there is any problem in data transmission, the whole display can still run normally.
9. Easy transportation: we will make flight cases with wheels for clients. So it is convenient for transportation.
