P6mm Stadium Perimeter LED Display
Basketball Ground P6 Indoor Full Color LED Screen LED Perimeter Boards With CE / ROHS
1. Quick Detail:
(1) Indoor SMD P6 Aluminum cabinet
(2) High definition
(3) Light weight and slim design
(4) Big View Angle
(5) High refresh rate
2. Description:
Dosatronics LED displays are high tech product with our own patent. Both outdoor or indoor LED display for advertising has high brightness, high contrast, high refresh rate…All are popular both in domestic and overseas market. We adopt unbeatable product stability through strict Quality Control System. It is very correct for you to choose our company, our LED display products. All of them has 3 years quality warranty since all component are extremely good. They can bring you large fortune in a very short time.
3. Applications:
Our Full Color SMD indoor P6 LED Display is mainly for indoor HD video wall usage, such as commercial advertising, conference, mobile media, night club, entertainment events, business establishments, can install in banks, stock exchange centers, bus station, schools, telecommunications, customs, stadiums, studio, shopping, malls, railways, airports, harbors, etc.
4. Specifications:
| Model No. | DS-AI-P6 |
| Pixel Pitch | 6mm |
| Module Size | 192*96mm |
| Module Resolution(pixels) | 32*16 |
| Cabinet Size | 576mm×576mm |
| Panel Resolution(pixels) | 96×96 |
| Pixel Configuration(RGB) | SMD 3 in 1 |
| Pixel Density(pixels/㎡) | 27777 |
| Brightness(cd/㎡) | 1000 |
| Best Viewing Distance(m) | 1-30 |
| Average Power Consumption(W/㎡) | 300 |
| Waterproof Level | IP45 |
| Drive Method | 1/8 scan |
| LED SPEC | 2121 |
| Viewing Angle | 140°(H)/140°(V) |
| Operating Temperature | –40~100 |
| Video Frame Rate(Hz) | ≥ 60HZ |
| Display Refresh Rate(Hz) | ≥ 1000HZ |
| Grey Level(colors) | 16.7million |
| MTBF | ≥50,000 hours |
| Lifespan | ≥100,000Hours |
| Working Voltage | 220V±15% OR 110V±15% |
| Wavelength | R 620-625 G 520-525 B 470-475 |
| Graphics Card | DVI Graphics card |
| Video Signal | RF, S-Video, RGB, RGBHV, YUV, YC, etc. |
| Control System | LINSN |
| Software | LED studio 10.0 |
| Installation | Wall mount, hung and stand structure |
