3840Hz Stage Rental LED Display
P3.2mm Stage Rental Led Display 3840hz High Refresh Rate For Outdoor
Features :
1. Black Shell SMD with High Brightness
5000 nits high brightness create good visibility for any outdoor and indoor events
2. Die Cast Aluminum Low Tolerence
Every Panel is manufactured with CNC auto-machines of high precision so that to guarantee its seamlessness during assembly.
3. Quick Installation
Handle and fast lock design enable quick and convenient installation and disassembly, one person can handle it all.
4. High Refresh Rate
3840Hz high refresh rate, no ghosting, no flicker, no moire, only perfect image
5. Front Service
Front maintenance design, easy maintenance.
6. Stable and Reliable
Under the patent of inlaying SMD into PCB, the stability is better than any other similar products in the market.
Product parameter
| Brightness | nits | 4000 | ||
| Color temperature | deg.k | 3200 ~ 9300 | ||
| Viewing angle - Horizontal | deg. | 160(+80/-80) | ||
| Viewing angle - Vertical | deg. | 160(+80/-80) | ||
| Cabinet weight | kg | 9 | ||
| Cabinet width | mm | 500 | ||
| Cabinet height | mm | 500 | ||
| Cabinet depth | mm | 90 | ||
| Cabinet area | sq. m. | 0.25 | ||
| Cabinet material | Aluminum | |||
| Aspect ratio | 1:1 | |||
| Ingress protection (Front/Rear) | IP | IP65/IP54 | ||
| Operating temperature range | deg. C | - 20 to 50 | ||
| Operating humidity range | HR | 10％ to 90％ | ||
| Pixel type and configuration | R/G/B | SMD 3in1 | ||
| Pixel pitch | mm | 3.205 | ||
| Pixel matrix per cabinet | 156x156 | |||
| Pixels per cabinet | 24336 | |||
| Lines per meter | 312 | |||
| Pixels per sq. meter | 97351 | |||
| LEDs per sq. meter | 97351 | |||
| Recommended minimum viewing distance | m | 3 | ||
| Colours | 281trillion | |||
| Gray scale | Levels | 65536 levels per colour | ||
| Brightness control | Levels | 100 | ||
| Digital processing | bit | 16 | ||
| Frame rate | Hertz | 60 | ||
| Display refresh rate | Hertz | 3840 | ||
| Input voltage | VAC | 110/240 | ||
| Input power frequency | Hertz | 50/60 | ||
| Input power (max/avg) | Watts per sq.m | 940/320 | ||
| MTBF | Hours | ≥10000 | ||
| Lifetime (50%Brightness) | Hours | ≥100000 | ||
| Module brightness uniformity | ＜5％ | |||
| Blind spot rate | ＜0.0001 | |||
| Earth leakage current | mA | ＜2 | ||
| Red wavelength | nm | 623 | ||
| Green wavelength | nm | 525 | ||
| Blue wavelength | nm | 470 | ||
| Panel input format (with video processor) | VGA,DVI,SDI,YPbPr(HDTV),Composite,S-Video,TV | |||
| Data interconnection | CAT6 cable/Fiber | |||
| Operating system | Windows(XP/Vista/7/8/10) | |||
| Control distance | Up to 180 meters by CAT6 cable, single fiber up to 15 kilometers. | |||
Advantages
1.Portable cabinet easy to install
2.Super Light weight and slim about 8kg/sqm
3.With Good heat dissipation
4.adjustable and High brightness
5.Save electricity compared with ordinary products
6. better viewing effect because of using high reflesh IC,
7.it has Larger viewing angle: Horizontal angle 140 degree/elevation angle 140 degree
