Curved IP43 P6 60Hz Flexible LED Curtain Screen
Curved Flexible Led Curtain Screen Slim Rental 60Hz Frame Easy Installation For Events
- Lightweight The aluminum die-casting technology makes the single cabinet as light as 14KG.
- Ultra thin The thinnest point of the cabinet is only 75mm, making it easily to be fitted in small room.
- Easy to install No need of other tools. It takes 15 minutes for 2workers to finished 30 sqm installation.
- High IP The IP43 insures the reliable operation in severe environment.
- Easy to maintain No need to disassemble the whole screen for maintenance. Each component can be detach individually for that purpose.
- Noiseless The aluminum structure requires no fan. Combined with the noiseless power supply, the cabinet is totally silent.
- Ghost canceling Exquisite and clear picture quality with no ghost. Both upstream and downstream ghosts can be automatically canceled.
- High refresh rate 3840Hz refresh rate to ensure the picture wrinkle-less, lineless and stable.
- Low brightness and high gray scale 14Bit-16Bit gray scale to bring excellent performance when brightness reduced to 20%.
| Indoor slim rental P3.91, P4.81, P5.68, P5.95, P6.25, P8.928mm models (unit module size: 250mm * 250mm and unit cabinet size: 500mm * 500mm) | |||||||
| LED Module | Pitch/mm | PH3.91 | PH4.81 | PH5.68 | PH5.95 | PH6.25 | PH8.928 |
| Module size/mm | 250*250 | 250*250 | 250*250 | 250*250 | 250*250 | 250*250 | |
| Density of pixel/(dots/m2) | 65536 | 43264 | 30976 | 28224 | 25600 | 12544 | |
| Pixel composition | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | |
| Led encapsulation | SMD 3 IN 1 | SMD 3 IN 1 | SMD 3 IN 1 | SMD 3 IN 1 | SMD 3 IN 1 | SMD 3 IN 1 | |
| Resolution of module | 64*64 | 52*52 | 44*44 | 42*42 | 40*40 | 28*28 | |
| LED Screen | Optimum viewing distance | 3~38M | 3~38M | 4~40M | 4~40M | 5~45M | 7~50M |
| View angle | H:±160°;V±120° | H:±160°;V±120° | H:±160°;V±120° | H:±160°;V±120° | H:±160°;V±120° | H:±160°;V±120° | |
| Average power consumption | 600W/sqm | 600W/sqm | 400W/sqm | 400W/sqm | 300W/sqm | 300W/sqm | |
| Max power consumption | 1600W/sqm | 1600W/sqm | 1000W/sqm | 1000W/sqm | 900W/sqm | 700W/sqm | |
| Module quantity | 2* 2pcs | ||||||
| Size of cabinet/mm | 500*500 | ||||||
| Resolution of cabinet | 128*128 | 104*104 | 88*88 | 84*84 | 80*80 | 56*56 | |
| Cabinet Material | die-casting aluminum cabinet | ||||||
| Weight of cabinet | 7.5Kg | ||||||
| Driving method | 1/16 scan constant current | 1/13 scan constant current | 1/11 scan constant current | 1/7 scan constant current | 1/10 scan constant current | 1/7 scan constant current | |
| Frame frequency / Hz/S | ≥60 | ||||||
| Refresh frequency/ Hz/S | 800~2000 | ||||||
| Brightness | 1500cd/m2 | 2000cd/m2 | 1500cd/m2 | 1500cd/m2 | 1500cd/m2 | 2500cd/m2 | |
Features:
it is super thin, very light weight and most flexible to design shapes, effects, in any types, arc in any angles. With repeating curving, it won't break LEDs as well design of mask covers.
1. Module with small-unit and flexible design,makes possiblity of more complicated shapes for the video show.
2. Assembling screen with soft led modules directly,saving time and effort,easy operation.
3. Magnet connection,easy to assemble & disassemble,it is frontal service maintenance.
4. No cabinet metal frame,drastically deducting the screen weight.we can design any shape of structure as you need.
5. Strict quality control and long-term application experience verified the stablity and excellent performance by using Epistar LED, and MBI5124 Driving IC for high refresh rate and performance.
6. Widely applied in shaped stage background/exhibition/shopping mall etc.
