P3.91mm Electronic Display SMD1921 Interactive LED Floor Tile
Price:
negotiable
MOQ:
negotiable
Delivery Time:
20 days after receiving the deposit
Brand:
jucaiyuan
Product Description
Full Color Interactive LED Screen Dance P3.91 Floor Tile Electronic Display
Description
- Front maintenance technology: Since the positioning pin on the product box hinders the box from being arbitrarily taken out from the large screen, it brings inconvenience to some on-site emergency maintenance. In response to this phenomenon, the product maintenance technology has played a decisive role. It is to make the box can be taken out from the big screen, which is convenient for on-site emergency maintenance. It is loved by customers. This technology will be necessary for the LED display industry. The development trend.
- The PCB circuit board is designed with a perforation: it is convenient to connect the plastic load-bearing face , load-bearing column and the bottom bottom case, and fix the PCB and the lamp bead in the plastic package to prevent the pedal from being damaged.
- Interactive technology should be more flexible to capture the movement of controlled objects, making interactive technology more flexible, accurate, error-free, and without delay.
- The screen body can be diversified, and it can also be installed vertically. The display effect is better than that of the indoor screen display, which makes the product diversified and feasible.
- High load-bearing performance: professional iron box material structure design, lighter weight, stronger structure, bearing capacity of 2-2.5 tons / m2.
Application:
Widely used in stage fixed installation,singing and dancing event evenings,various conferences,exhibitions,stadiums,theaters,auditoriums,lecture halls,multi-purpose halls,conference rooms,interpretation halls,di bars,night clubs,high-end entertainment discos,TV station Spring Festival Evening,auto show,important cultural events in various provinces and cities.
| Pixel composition arrangement form | vertical |
| Pixel tube spacing | 6.25mm |
| Pixel composition | 1R1G1B (three in one) |
| Lamp Bead Model | SMD1921 (Chip Scale 3:6:1) |
| Physical density | 25600 points / m2 |
| Module / Case Size | 250 Width × 250 Height (mm) |
| Module resolution | 40 Width × 40 Height (Point) |
| Cabinet size | 500 (width) × 1000 (height) mm |
| Box weight | 22.5KG / piece |
| Box thickness | 9cm (including module thickness) |
| Full screen parameters | Out of control point ≤3/100000 |
| Unit module joint seam | The unit board gap joint seam size is consistent, and ≤ 2mm |
| Optimum distance | 5-60m |
| Angle of view | horizontal 140°, vertical 140° surface flatness Maximum error ≤ 2mm |
| The color of the screen surface is the same, the ink is the same, no reflection | |
| Uniformity Module brightness uniformity | 1:01 |
| Power supply use environment | |
| Operating humidity range | 10% to 90% RH |
| Operating temperature range | -20 to 65 °C |
| Maximum power | 600W/m2 |
| Average power | 300W/m2 |
| Control system | control host operating system XP computer + control software hardware + playback software and hardware |
| Control mode | Synchronize with computer VGA (display sync) |
| Control system | DVI graphics + full color control card + fiber transmission Input method Computer and other peripherals, PAL/NTSC/SECAM, S-Video; VGA; RGB; Composite Video; SDI, etc. |
| Screen function | technical parameters LED drive constant current drive (10 sweep) |
| Computer display mode | 640 × 480, 800 × 600, 1024 × 768 |
| Refresh rate | 2000hz |
| Grayscale / color | 8192 |
| Full screen brightness | 2500 cd/m2 |
| Service life | 100,000 hours or more |
| Display content | Video DVD, VCD, TV, images, text, animation, and more. |
| Continuous trouble-free working time | ≥10000 hours |
| Interface Standard | Ethemer network interface, communication uses RS-422 communication medium, control distance Multi mode fiber <500m, single mode fiber transmission < 30km, Category 5 line < 100m |
| Protection technology | moisture-proof, dust-proof, anti-corrosion, anti-static, lightning-proof, with over current, short circuit, over voltage, under voltage protection |
| Software | General LED video playback software (conventional), custom player (intelligent sensing) |
Competitive advantages:
- Installation service, usually we are not responsible for overseas installation, but we can
- Provide technical support for you. If you need to install the service, we can send us
- Technicians come to your country, but the cost is paid by the customer.
- Free lifetime maintenance and software upgrades.
- If you have any questions about the led display, we will reply you within 24 hours.
- Provide maintenance instructions and problem resolution within 48 hours.
- Provide customers with loaders so they can be used immediately after installation
- Led display, no need to debug
- Free technical training on how to use and process software.
