16bit Interactive LED Floor Tile
Outdoor Interactive LED Floor Tile Anti-Scratch Mask Interactive Glass Bridge
Description
As the development of tourist , the glass brige is more and more popular . So the market produce a new led display- glass floor led display. It adopts anti-scratch mask marterial , and interactive system. With infrared ray human motion perception and accurately in the floor tile of the LED display screen motion object change stage effect such as immersive graphics make it wan, the imaging range according to different scenarios, different requirements and increase the display area, and radar sensing technology, it is according to the doppler effect for certain base, by now the most advanced planar antenna technology, the most important can effectively inhibit vertical harmonic and some other noise interference, very high sensitivity, strong reliability, security intelligent energy-saving
Floor LED Display Feature:
- High contrast design: technical design mask, clear play effect.
- More uniform heat dissipation,Enhance display effect and extend life span
- Easy and Fast Maintenance, With real wireless design inside of the cabinet, it is more stable for the transmission of signal and power
- Adopts the hardest hign polymer material-Polycarbonate as mask,prevent damage from scratch,hit,hign temperature,and corrosion.
Floor LED Display Parameter:
| Product Item | LW-6 |
| Pixel Pitch | 6.25 mm |
| Pixel Configuration | SMD 2727 |
| Pixel Density | 25,600 pixels/m² |
| Module Dimensions (W × H) (mm) | 250 × 250 |
| Panel Dimensions (mm) | 500 × 1000 |
| NO.of Modules Per Panel (W × H) | 2 × 4 |
| Physical Resolution of Module (W × H) | 40 x 40 |
| Physical Resolution of Panel (W × H) | 80 x 160 |
| Panel Material | Aluminum |
| Single Cabinet Weight | 24 kg/panel |
| ray Scale | 16 bit |
| Colours | 281 trillion |
| Contrast Ratio | 4,000 : 1 |
| Average Power Consumption | 300 W / m² |
| Max Power Consumption | 880 W / m² |
| Operating Temp/Humidity | -10ºC-60ºC / 10%-60% |
| Storage Temp/Humidity | -30ºC-60ºC / 10%-60% |
| Refresh Rate | >1,920 Hz |
| Brightness | 4,500 nits |
| Horizontal Viewing Angle | 160° |
| Vertical Viewing Angle | 140° |
| Expected Lifetime | 100, 000 Hrs |
| Best Viewing Distance | 8m |
| Scan Method | 1 / 5 Scan |
| Servicing | Front |
| IP Rating | IP 65 |
| Notes: Specifications are for reference only. Please contact our salesperson for details. All rights are reserved to Led World. | |
