Wireless IP21 400Hz 6000nit LED Scrolling Display Board
Outdoor Programmable LED Signs Wireless LED Scrolling Message Display Board
What color do you want for led moving sign?
we have single color: red, blue, yellow, orange, green, white for you
we have double colors: RG,RB,RW or you can select
we have full colors for indoor and outdoor led display
Do you have aluminium alloy cabinet/case?
yes, we have iron cabinet and aluminium alloy for your choose
Do you want custom make led scrolling sign here?
yes, we can, please tell us what is your enquiry.
Product Description:
The Unique Advantages:
The unique : No Need Driver, No need CD and do not worry lost the Software
The unique : High capacity battery of 300MAH,and working 20Hours
The unique : USB Charger Line same with Mobile (Android System)
Software HDSmart setting more animations ,photos and Texts
The unique : Support Temperature directly
All languages
Technology Specifications
| Brightness | nits | 6000 |
| Color temperature | deg.k | 6500 |
| Viewing angle - Horizontal | deg. | 120 |
| Viewing angle - Vertical | deg. | 60 |
| Cabinet Weight | kg | 41 |
| Cabinet Width | mm | 1024 |
| Cabinet height | mm | 768 |
| Cabinet depth | mm | 185 |
| Cabinet area | sq. m. | 0.79 |
| Cabinet material | Aluminium | |
| Aspect ratio | 6:05 | |
| Ingress Protection (Front/Rear) | IP | IP65/IP21 |
| Operating temperature range | deg. C | -20 to 50 |
| Operating Humidity range | HR | 10% to 90% |
| Pixel type and configuration | R/G/B | 1,1,1 |
| Pixel pitch | mm | 10.667 |
| Pixel matrix per cabinet | 96 x 72 | |
| Pixels per cabinet | 6912 | |
| Lines per meter | 94 | |
| Pixels per sq. meter | 8789 | |
| LEDs per sq. meter | 26367 | |
| Recommended minimum viewing distance | m | 10 |
| Colours | 1.07Billion | |
| Gray scale | Levels | 1024 levels per colour |
| Brightness control | Levels | 100 |
| Digital processing | bit | 10 |
| Frame rate | Hertz | 60 |
| Display refresh rate | Hertz | ≥400 |
| Scan mode | 1/4 duty scan driv | |
| Input voltage | VAC | 110 to 240 |
| Input power frequency | Hertz | 50 or 60 |
| Input power (max/avg) | Watts per sq.m | 600/250 |
