Synchronization 320x160mm Outdoor Full Color LED Display

Price Negotiable
Price: negotiation
MOQ: 3 Square meters
Delivery Time: 5-10 days
Brand: JuCaiYuan
Product Description

P10 Outdoor Full Color LED Display Synchronization With PC Control Playground



Feature


1. Big viewing angle to at horizontal line, 140 degree at vertical line, you can see at every angle at this range, no picture change, no color excursion.
2. To pictures and character, have clear, exquisite and real display effect.
3. High intensity and can be adjusted, so can meet the request of the customers according the application environment.
4. Thermostatically controlled fan: Unique temperature control design works only when the temperature is higher than the pre-set temperature.
5. Flat screen, no gap. Cabinets were made by high-precision molding plastic injection, no slit on the screen.
6. Easy Installation & Using: Easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED screen system.
7. The SMD three-in-one technology with high brightness makes the display has a ultra-wide view and smoother pictures when in use.



Quick Detail



1. Lightweight:50kg/sqm;

2. Ultra Thin Design:the thickness of cabinet with backdoor is only 13.5cm;

3. 3 angles of corner display:90°/115°/135°;

4. DIP or SMD optional;

5. Customized products.





Specifications :



Technical Specification
Pixel Pitch 10mm
Pixel Dendity 10000pixels/sqm/㎡
Pixel Configuration 1R1G1B
Module Size 320mmx160mm
Body size 640mmx640mm/960mmx960mm
Pixels/Module 32x16=512
Driving Method 1/4scan/1/2scan
Optimal Viewing Distance >10m
Operating Temperature -20°C ~ +50°C
Optimal Viewing angle Horizontal 140 / vertical 140
Maximum Power Consumption 1500w/sqm
Average Power Consumption 500w/sqm
Brightness 5000cd/㎡
Refresh Rate 1000-3000 Hz adjustable
Power Supply 220V/50HZ/110V/60HZ
