P4mm High Refresh Rate LED Wall Screen Display Outdoor
Feature
1) High intensity and can be adjusted, so can meet the request of the customers according the
application environment.
2) Best equality, commendably solve the problem of the mosaic, have the excellent consistency
of light.
3) To pictures and character, have clear, exquisite and real display effect.
4) Big viewing angle to 140 degree at horizontal line, 140 degree at vertical line, you can see
at every angle at this range, no picture change, no color excursion.
5) High brightness, can be adjusted to different environment.
Accessories
Module 9pcs
Power Supply 1pc
Power Connector 2sets
Signal Connector 2sets
Receiving Card 1pc
Fan 1set
Lock 4sets
Specifications :
| Item | P4 |
| Pixel Pitch | 4mm |
| Pixel Configuration | SMD 3in1 Epistar brand leds |
| LED Encapsulation | SMD2525 |
| Pixel Density | 62500dots/㎡ |
| Brightness | ≥6500cd/㎡ |
| Module Size | 256*128mm |
| Scan mode | 1/8S |
| Unit cabinet | 512*512mm |
| Unit cabinet Resolution | 128*128 |
| Cabinet weight | 14kg |
| Max. Power Consumption(w/㎡) | ≤700 |
| Aver. Power Consumption(w/㎡) | ≤230 |
| Viewing angle | H:140°V:140° |
| Refresh rate | >1200HZ |
| Gray grade | 65536 for each color |
| Best Viewing distance | 4-100m |
| Cabinet Material | Die-Casting Aluminum |
| Power Input | AC:110-240V/47-63Hz |
| Working Tem./Hum. | -25-60℃ |
| Operating System | Andriod/Windows |
