IP67 Flexible LED Curtain Screen
Features:
it is super thin, very light weight and most flexible to design shapes, effects, in any types, arc in any angles. With repeating curving, it won't break LEDs as well design of mask covers.
1. Module with small-unit and flexible design,makes possiblity of more complicated shapes for the video show.
2. Assembling screen with soft led modules directly,saving time and effort,easy operation.
3. Magnet connection,easy to assemble & disassemble,it is frontal service maintenance.
4. No cabinet metal frame,drastically deducting the screen weight.we can design any shape of structure as you need.
5. Strict quality control and long-term application experience verified the stablity and excellent performance by using Epistar LED, and MBI5124 Driving IC for high refresh rate and performance.
6. Widely applied in shaped stage background/exhibition/shopping mall etc.
| Physical Pitch | 25mm | 25mm(H) 35mm(V) | 25mm(H) 35mm(V) | 31.25mm | 31.25mm(H) 50mm(V) |
| Physical Configuration | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B |
| Pixel Density | 1,600 pixels/sqm | 1,120 pixels/sqm | 800 pixels/sqm | 1,024 pixels/sqm | 640pixels/sqm |
| Unit Size(W*H)(mm) | ≥1500*250 | ≥1500*250 | ≥1500*250 | ≥1500*250 | ≥1500*250 |
| Physical Resolution of Unit (H*V) | 60*10 | 60*7 | 60*5 | 48*8 | 48*5 |
| Panel Material | Aluminum | Aluminum | Aluminum | Aluminum | Aluminum |
| Weight | 15kg/sqm | 10.6kg/sqm | 8.5kg/sqm | 15kg/sqm | 9.6kg/sqm |
| Processing | 16bit | 16bit | 16bit | 16bit | 16bit |
| Contrast Ratio | 2000:1 | 2000:1 | 2000:1 | 2000:1 | 2000:1 |
| Average Power Consumption | 150W/sqm | 115W/sqm | 85W/sqm | 107W/sqm | 67W/sqm |
| Max Power Consumption | 450W/sqm | 345W/sqm | 255W/sqm | 329W/sqm | 200W/sqm |
| Brightness | ≥7,500nits | ≥6,500nits | ≥5,000nits | ≥6,500nits | ≥4,000nits |
| Refresh Rate | ≥3.840Hz | ≥3.840Hz | ≥3.840Hz | ≥3.840Hz | ≥3.840Hz |
| Horizontal Viewing Angle | 120° | 120° | 120° | 120° | 120° |
| Vertical Viewing Angle | 60° | 60° | 60° | 60° | 60° |
| Servicing | Front/Rear | Front/Rear | Front/Rear | Front/Rear | Front/Rear |
| IP Rating(Front/Rear) | IP67 | IP67 | IP67 | IP67 | IP67 |
