2021 New Indoor/outdoor led screen P3 P3.33 p3.91 p4.81 500x500 stage rental P3.91 outdoor curve led display screen 500x
Price:
negotiation
MOQ:
1 Square meter
Delivery Time:
3-25 working days after finished the payment
Brand:
JuCaiYuan
Product Description
Overview
| Item Name | Parameter | |||
| Model No | LM-P3.91-S | LM-P4.81-S | LM-P5.95-S | LM-P6.25-S |
| Module size | 250mm*250mm | 250mm*250mm | 250mm*250mm | 250mm*250mm |
| Pixel pitch | 3.91mm | 4.81mm | 5.95mm | 6.25mm |
| Pixel Density | 65410 pixels/m2 | 43222 pixels/m2 | 28246 pixels/m2 | 25600 pixels/m2 |
| Pixel configuration | 1R1G1B | 1R1G1B | 1R1G1B | 1R1G1B |
| LED Package mode | SMD2727 | SMD2727 | SMD3535 | SMD3535 |
| Module resolution | 64dots(H)*64dots(V) | 52dots(H)*52dots(V) | 42dots(H)*42dots(V) | 40dots(H)*40dots(V) |
| Drive type | Constant drive | Constant drive | Constant drive | Constant drive |
| Brightness of white balance | ≥7000cd/m2 | ≥7000cd/m2 | ≥7000cd/m2 | ≥7200cd/m2 |
| Cabinet Dimension | 500mm x 500mm x 85mm | 500mm x 500mm x 85mm | 500mm x 500mm x 85mm | 500mm x 500mm x 85mm |
| Module Quantity | 4pcs | 4pcs | 4pcs | 4pcs |
| Cabinet Resolution | 128*128 | 104*104 | 84*84 | 80*80 |
| Cabinet Weight | 10.5kg per cabinet | 10.5kg per cabinet | 10.5kg per cabinet | 10.5kg per cabinet |
| Cabinet Material | Die Casting Aluminum | Die Casting Aluminum | Die Casting Aluminum | Die Casting Aluminum |
| Best viewing distance | 3.91M~40M | 4.81M~40M | 5.95M~40M | 6.25M~40M |
| Best viewing angle | 140°(H) 65°(V) | 140°(H) 65°(V) | 140°(H) 65°(V) | 140°(H) 65°(V) |
| Average Power consumption | 450W/m2 | 400W/m2 | 400W/m2 | 400W/m2 |
| Max.Power consumption | ≤800W/m2 | ≤800W/m2 | ≤800W/m2 | ≤880W/m2 |
| Frame Frequency | ≥60Hz | ≥60Hz | ≥60Hz | ≥60Hz |
| Refresh frequency | ≥3840HZ | ≥3840HZ | ≥3840HZ | ≥3840HZ |
| Power Supply Mode | AC220±10% 50Hz/AC110±10% 60Hz | |||
| Temperature | storage:-35℃~+85℃ | |||
| working:-20℃~+50℃ | ||||
| Humidity | 10%-95% | |||
| IP Grade | IP65 | |||
| Grey scale/colors | 256levels of each color(RGB)/16.7M colors | |||
| MTBF | ≥5,000hours | |||
| Screen Lifespan | ≥100,000 hours | |||
| Screen Plainness | <±1mm | |||
| Blind Spot Rate | <0.0001 | |||
| CPU | Pentium4 or above | |||
| Operation system | WIN10/12/NT/XP | |||
| Control method | Synchronous display with control PC by DVI | |||
| Control System | Linsn, Nova-star, Colorlight or as you required | |||
| Display Content | Video, DVD, VCD, TV, picture, cartoon, graphics, texts.etc. | |||
| Interface | Standard Ethernet | |||
| Transmission Distance | Multi mode fiber <500m, single mode fiber <30km,internet cable | |||
| Certificate | CE, RoHS, FCC | |||
| Application | Outdoor, Indoor Rental Purpose | |||
Nationstar Gold Wire SMD LED Lamp Chip
Novastar LED Video Controller Card System
Leeman Display LED Video Processor 4k
Meanwell Power Supply Wtih Certification
4 Layer PCB Board With 1.6mm Thickness
MBI5153 MBI5155 MBI5252 Driving IC
High Refresh Rate 6420Hz - 6800Hz
Hight Brightness 9000nits- 10000nits
