Parker P16 Iron And Aluminium Gear Pump 702D-66+66+16.7(2+3) 14T R-1

Parker P16 Pump – Iron And Aluminium Gear Pump 702D-66+66+16.7(2+3) 14T R-1

Parker P16 pumps are fixed displacement gear pumps. They offer a combination of high performance and light weight as they have a rugged cast iron pumping section with aluminum flange and port end covers. This makes the P16 ideal for the mobile and truck markets.

Formerly made by Gresen, the Parker P16 series is available as:

• P16 – standard pump
• TP16 – tandem pump, 2 and 3 place
• PVP16 – with priority valve
• CP16 – clutch pump, V belt and serpentine
• TP-PVP – combination P16 with priority valve
• PB16-P2 – piggy back
• HP16 – high pressure
• THP16 – tandem, high pressure
• FPR16 – cast iron, bi-directional

Standard P16 pump models are: P16-45 | P16-65 | P16-85 | P16-100 | P16-115 | P16-150 | P16-180 | P16-200 with displacements from 14cc/rev to 64/cc/rev – see the technical details tab for more information.

Features and benefits of Parker P16 series pumps are:

• Three-piece construction for distribution flexibility
• Cast iron pumping sections for durability
• Aluminum cover plate and flange for excellent power to weight ratio
• Journal bearings for long life
• Multiple sections available
• Flow range to 143.8 litres/minute per section, the TP16 is 121 litres/minute
• Priority flow range 7.5 to 37.8 litres/minute standard (PVP16 only)
• Operating pressures up to 207 bar (3,000 psi)
• Speeds up to 3,600 rpm
• Clockwise and counter-clockwise pumps available
• SAE shafts, flanges and porting available

Contact us for further technical details and configuration options.
