Triple Play 1 GE EPON ONU 3FE WIFI IPTV FTTH ONU Same As HuaWei Hg8245h
Triple Play EPON ONU 1GE 3FE WIFI IPTV FTTH ONU Same As HuaWei Hg8245h
Main features:
Built in 700MHz high performace ARM cortex A9 RISC process(32KB I/32KB D L1Cache,256KL2Cache),support MMU,bulit in 250MHz higher formance DSP processor.
GPON compliant with ITU-T G.984.1/2/3/4,1.244Gbit/s;,upstream speed 2.488Gbit/s,upstream 1.244Gbit/s,EPON compliant with 802.3-2005 and CTC EPON technic requirements.EMS network management based on SNMP ,convenient for maintenance.
Full speed non-blocking switching.Support QinQ VLAN, 1:1 VLAN, VLAN reusing, VLAN trunk, etc.Integrated port monitoring, port mirroring, port rate limiting, port SLA, etc.Support auto polarity detection of Ethernet ports (AUTO MDIX).Integrated IEEE802.1p QoS with four level priority queues.
Technical Specifications:
| Hardware | |||
| Shell: | Plastic housing | Working Enviornment | Operating temperature: 0 to 50ºC |
| Ports: | 1GE+3FE | Storage temperature: -40 to 85ºC | |
| Weight: | 0.2kg/pc | Operating humidity: 10% to 90%(Non-condensing) | |
| Indicator: | Power/PON/LOS/LAN/WPS/WLAN | Storage humidity: 10% to 90%(Non-condensing) | |
| Port datasheet | |||
| PON Parameter | Wavelength: Tx 1310nm, Rx1490nm | Ethernet | VLAN Tag/UNTAG |
| Tx Optical Power: 0~4dBm | Q in Q VLAN | ||
| Rx Sensitivity: -27dBm | MAC address restricion | ||
| Two direction FEC(Forward Error Correction) | MAC address learning | ||
| authertation: SN/password/LOID(GPON); MAC/Key/LOID(EPON) | WLAN |
IEEE802.11b/g/n antenna attenuation:2dBi multi SSID |
|
| Optical Fiber: 9/125 single-mode fiber | WPS | ||
| Function: | |||
| QoS | Port-based speed limitation | O&M | OMCI/Web UI |
| 802.1p Priority | 802.1ag Ethernet OAM | ||
| SP/WPR/SP+WRR | loop detection | ||
| message speed limit | optical link supervision | ||
| Security | SPI firewall | Multicast | IGMP v2/v3 snooping |
| MAC/IP/URL filter | MLD v1/v2 snooping | ||
| downstream VLAN switch/ transparent transmit | |||
| Operation | PPPOE/DHCP proxy test | IGMP/MLD message speed limitation |
