Gigabit Bridge Type 1 GE EPON ONU , Single Port Wifi GPON ONT SC/PC Connector
Price:
Negotiable
MOQ:
1pcs
Delivery Time:
5 work days
Brand:
JiZhong
Product Description
Gigabit Bridge Type 1GE Single Port GPON EPON FTTH ONU ONT 1 FE ONU
Product Descriptions:
It is a bridge-type ONT/ONU used in the all-optical access solution. It implements ultra-broadband access through the GPON technology. It provides 1 GE ports. The high-performance forwarding capability ensures the service experience of data and HD video services, and provides users with ideal terminal solutions and future-oriented service support capabilities.
Technical PArameters:
| Technical items | Descriptions |
|
Upstream PON interface |
1 EPON interface, SC single-mode/single-fibre, symmetric 1.25Gbps |
| Wavelength | Tx 1310nm, Rx 1490nm |
| Optical interface | SC/PC connector |
| Downstream LAN interface | 1*10/100/1000Mbps auto adaptive Ethernet interface, Full Duplex/Half Duplex, RJ45 connector |
| Indicators | 4 indicators, for status of power, PON port and 1 Giga-Ethernet port. |
| DC power supply | +12V@0.5A, external AC-DC power adaptor |
| Power consumption | <5W |
| Operating condition | Operating temp: -5 - +55℃, operating humidity:10-90%(non-condensed) |
| Storing condition | Storing temp: -30 - +60℃, storing humidity:10-90%(non-condensed) |
| Device Dimension | 115mm*75mm*28mm (length*width*height) |
| CANTON Dimension |
Package: 365mm*350mm*235mm 10PCS/CTN |
| Net weight | 0.03Kg |
