31N9-10150 31N8-10180 31N8-10181 Hyundai Excavator Swing Reduction Gearbox R305-7 R335-7 R305-9 R335-9
31N9-10150 31N8-10180 31N8-10181 Hyundai Excavator Swing Reduction Gearbox R305-7 R335-7 R305-9 R335-9
Product Features
| Appliion | Hyundai Excavator |
| Part name | Swing gearbox |
| Material | Steel |
| Model | R210 R210LC-7 R215-7,R305-7 R335-7 R305-9 R335-9 |
| MOQ | 1PC |
| Warranty | 3 months |
| Payment term | T/T&Western Union &Paypal |
| Delivery Time | Within 2 days after receiving the payment |
| Packing | Standard shipping package |
List of spare parts
| # | Part No | Part Name | Qty. | Part No | Part Name | Qty. |
| 1 | @ | FUEL INJECTION PIPE & NOZZLE | 1 | XKAQ-00111 | RING-SPACER | 1 |
| SEE 4100 | XKAQ-00053 | PIN-KNOCK | 4 | |||
| 2 | 31E9-01052 | SWING REDUCTION GEAR | 1 | XKAQ-00028 | BEARING-ROLLER | 1 |
| XKAQ-00141 | CASING-FRONT | 1 | XKAQ-00027 | BEARING-ROLLER | 1 | |
| 3 | XKAQ-00279 | CASING-FRONT | 1 | XKAQ-00052 | BOLT-SOCKET | 16 |
| XKAQ-00329 | CASING-FRONT | 1 | XKAQ-00051 | BOLT-SOCKET | 12 | |
| 4 | XKAQ-00003 | CASING-MIDDLE | 1 | XKAQ-00138 | SEAL-OIL | 1 |
| XKAQ-00113 | SHAFT-DRIVE | 1 | XKAQ-00280 | SEAL-OIL | 1 | |
| 5 | XKAQ-00328 | SHAFT-DRIVE | 1 | XKAQ-00330 | SEAL-OIL | 1 |
| XKAQ-00006 | GEAR-RING 2 | 1 | XKAQ-00050 | PIN-SPRING | 3 | |
| 6 | XKAQ-00022 | GEAR-PLANET 2 | 3 | XKAQ-00049 | PLUG-PRESSURE | 1 |
| XKAQ-00012 | GEAR-2 SUN | 1 | XKAQ-00048 | PIN-SPRING | 3 | |
| 7 | XKAQ-00008 | GEAR-RING 1 | 1 | XKAQ-00047 | RING-STOP | 1 |
| XKAQ-00137 | GEAR-PLANET 1 | 3 | XKAQ-00045 | RING-STOP | 1 | |
| 8 | XKAQ-00061 | GEAR-1 SUN | 1 | XKAQ-00292 | WASHER-LOCK | 1 |
| XKAQ-00016 | CARRIER | 1 | XKAQ-00013 | GEAR-PINION | 1 | |
| 9 | XKAQ-00021 | PIN ASSY NO.2 | 3 | XKAQ-00296 | PLATE-LOCK | 1 |
| XKAQ-00060 | PIN ASSY-2 | 3 | XKAQ-00042 | BOLT-HEX | 2 | |
| 10 | XKAQ-00046 | BUSHING 2 | 3 | XKAQ-00041 | RING-STOP | 3 |
| XKAQ-00059 | WASHER-THRUST | 6 | XKAQ-00040 | PLATE-SIDE 2 | 3 | |
| 11 | XKAQ-00058 | BUTTON-THRUST | 1 | XKAQ-00109 | CIRCLIP | 1 |
| XKAQ-00136 | PIN ASSY 1 | 3 | XKAQ-00110 | V-SEAL | 1 | |
| 12 | INC NEEDLE CAGE | @ | FUEL INJECTION PIPE & NOZZLE | 1 | ||
| XKAQ-00057 | PLATE-SIDE 1 | 3 | XKAQ-00034 | BAR-GAUGE | 1 | |
| 13 | XKAQ-00056 | MAGNET | 4 | XKAQ-00035 | PIPE-GAUGE | 1 |
| XKAQ-00055 | PLATE-SIDE 3 | 1 |
Related Excavator Swing gearbox We Supply
| Brand | Model |
| KOMATSU | PC40, PC60-5-6-7, PC100, PC120, PC130, PC240, PC270, PC300,PC360,PC400,PC450,PC650,PC1250 |
| PC200-1-3-5-6, PC220-1-3-5, PC300-3-5, PC400-1-3-5, D20, D30, D31, D50, D60, D75, D80 (D85), D155 | |
| HITACHI | EX40, EX60, EX150, EX100M, EX100, EX120, EX150, |
| EX200-1-2-3, EX300-1-3-5, EX400, ZX450,ZX470,ZX870,ZX1200 | |
| EC | EC55/60, EC140,EC210, EC240, EC290, EC360, EC460, EC700 |
| Doosan | DH215, DH220, DH260, DH280, DH300, DH370, DH420, DH450, DH500 |
| Hyundai | R200, R210, R225, R265, R335, R455, R505 |
| Kato | HD250, HD400 (HD450), HD500, HD550, HD700 (HD770), HD800, HD820, HD850, DH880, HD1020, HD1220 (HD1250), HD1430, DH1880 |
| Kobelco | SK200,SK210, SK220,SK260, SK300, SK330, SK350, SK450,SK460,SK480,SK800 |
| Sumitomo | SH120, SH200, SH280, SH300, SH350, SH400, SH450, SH460, SH700 |
Hot sale products
About Us
Guangzhou Huilian Machinery Equipment Co., Ltd. Our company was established in 2011.
Huilian is a professional spare parts manufacturer and reliable supplier, providing almost all spare parts for
various models rock breakers.
Specializes in:
Excavator accessories
Hydraulic breaker accessories
Breaker Spare Parts Suitable for the brands: SOOSAN, FURUKAWA, KRUPP, ATLAS-COPCO, EDT, JCB, NPK, ,
HANWOO, TOKU, FINE, OKADA, SAGA, MONTABERT, INDECO, KWANGLIM, RAMMER, KONAN, KOMATSU,
GENERAL etc. Excavator Spare Parts Suitable for the brands: CATEEEEEEEEEEEE, KOMATSU, HITACHI, EC, KOBELCO,
cx, SUMITOMO, DOOSA, NHYUNDAI, SANY, XG ect. The logistics in Guangzhou is very convenient that
we deliver goods to the whole world.
