40ton 50ton Heavy Demolition Excavator Attachments Hydraulic Concrete Rock Breaker Hammer
The hydraulic breaker hammer is powered by pressure oil supplied from the pumping station of the excavator or loader and is more effective in the role of excavating building foundations to clear floating stones and soil from rock crevices. The principle of selecting a hydraulic breaker is to choose the most suitable hydraulic breaker according to the excavator model and the environment in which it will operate.
40ton 50ton Heavy Demolition Excavator Attachments Hydraulic Concrete Rock Breaker Hammer
| Product Name | HYDRAULIC BREAKER |
| Model | EB165 EB175 |
| Product Details | Hydraulic breakers are powerful attachments used to break up rock, concrete, and other tough materials. They work by converting hydraulic pressure into impact energy, allowing for efficient demolition in construction and mining appliCATEEEEEEions. Available in various sizes and designs, hydraulic breakers are a versatile tool for heavy equipment operators. |
| AppliCATEEEEEEion | Excavator Attachment |
Why choose us:
1. Our company has the complete pre-sale and after-sale system. For hydraulic breakers, we can provide 12 months of warranty time and we are at your service 24 hours a day.
2. The products are exported to most countries in the world with high quality, standards and have an excellent industry reputation.
3. numerous design patents to continuously improve the quality of our products.
4. The product models conform to all the small, medium and large excavators on the market, and the strike force and durability are leading the industry level.
5. Using high-quality steel, professional heat treatment technology, and skilled workers to produce each hydraulic breaker. We are also constantly improving to better serve global customers!
--Hydraulic breaker parts
SIDE TYPE
Side-mounted, suitable for side-mounted on excavator for breaking operations.
Robust structure, fine selected material, more durable. Semi-open shell for easy maintenance.
TOP TYPE
Top-mounted, suitable for top-mounted excavator for breaking operations.
The upper rotating head can be replaced, wide applicable.
Long overall length, long crushing distance.
Semi-open shell for easy maintenance.
SILENCED TYPE
Top-mounted, suitable for top-mounted on an excavator for breaking operations.
Fully enclosed structure, low noise
The upper rotating head can be replaced, wide applicable.
Long overall length, long crushing distance.
Huilian hydraulic breaker has three different styles, side type, top type and box type, they are suitable for different excavator models and backhoe loders, with below features:
* 12 months warranty
* longer service life
* good material and Korean technology
* longer warranty
* customized sizes
* any color and logo
* reasonable price
| MODEL | WEIGHT(KG) BOX TOP SIDE |
LENGTH(MM) BOX TOP SIDE |
REQUIRED OIL FLOW L/MIN |
WORKING PRESSURE KG/CM M2 |
IMPACT RATE B.P.M |
HOSE DIAMETER B.P.M |
CHISEL DIAMETER IN |
CHISEL LENGTH MM |
APPLICABLE EXCAVATOT M3 |
| EB-155 | 2800 2300 2670 | 3254 3083 2776 | 18O-240 | 160-180 | 300-450 | 1~1/4 | 155 | 1400 | 1.1-1.4 28-35 |
| EB-165 | 340D 3200 3350 | 3450 3500 3000 | 200-260 | 160-180 | 250-400 | 1~1/4 | 165 | 1500 | 1.2-1.7 30-45 |
| EB-175 | 4200 4200 3500 | 3709 3617 3200 | 210-290 | 160-180 | 200-350 | 1~1/4 | 175 | 1500 | 1_4-2.0 40-55 |
| EB-180 | 4500 4500 4200 | 38oD 3800 3300 | 250-340 | 160-180 | 250-320 | 1~1/4 | 180 | 1600 | 1.9-3.5 45-60 |
| EB-185 | 4500 4500 4200 | 3800 3800 3300 | 250-340 | 160-180 | 250-320 | 1~1/4 | 180 | 1600 | 1.9-3.5 45-60 |
| EB-190 | 4650 4650 4350 | 3750 3750 3260 | 260-320 | 170-190 | 200-300 | 1~1/2 | 190 | 1600 | 1.9-4.5 45-75 |
| EB-195 | 4650 46504350 | 3750 3750 3260 | 260-320 | 170-190 | 200-300 | 1~1/2 | 190 | 1600 | 1.9-4.5 45-75 |
| EB-210 | 6350 6200 6100 | 4550 4500 4350 | 280-390 | 160-180 | 200-350 | 1~1/2 | 210 | 1800 | 3.8-7.5 70-100 |
