CATEEEEEEE 305.5E 423-0097 Excavator Hydraulic Pump Main Piston Pump CATEEEEEEE-4230097 Parts
CATEEEEEEEEEEEEEE 305.5E 423-0097 Excavator Hydraulic Pump Main Piston Pump CATEEEEEEEEEEEEEE-4230097 Parts
CATEEEEEEEEEEEEEE305E 305.5E Excavator Main Pump
Spare Parts for your CATEEEEEEEEEEEEEE 305.5E 305.5E2 Mini Excavator Pump GP-Main Hydraulic
| Pos. | Part No | Qty | Parts name | |
| 1 | 6R-7943 M | [2] | SCREW M5X0.8X15-MM | 6R7943 |
| 2 | 180-6213 | [1] | RING-RETAINING | 1806213 |
| 3 | 258-0139 | [1] | SEAL-SHAFT | 2580139 |
| 4 | 2M-9780 | [3] | SEAL-O-RING | 2M9780 |
| 5 | 386-6610 | [1] | SPRING | 3866610 |
| 6 | 9X-8979 | [1] | DOWEL | 9X8979 |
| 7 | 8T-2503 M | [4] | BOLT-SOCKET HEAD M14X2X35-MM | 8T2503 |
| 8 | 168-3504 | [2] | SEAL | 1683504 |
| 9 | 258-0135 | [2] | PLUG | 2580135 |
| 10 | 190-6507 | [1] | RING-STOP | 1906507 |
| 11 | 9W-2110 | [1] | CUP-TAPERED ROLLER | 9W2110 |
| 12 | 8J-0412 | [1] | CUP-BEARING | 8J0412 |
| 13 | 192-7470 | [1] | SEAL-O-RING | 1927470 |
| 14 | 168-2203 | [1] | SHIM-SHAFT (3-MM THK | 1682203 |
| 15 | 386-6612 | [1] | BEARING-CRADLE | 3866612 |
| 16 | 386-6611 | [1] | BEARING-CRADLE | 3866611 |
| 17 | 398-7457 Y | [1] | VALVE GP-PUMP CONTROL |
3987457 |
| 18 | 379-5187 | [1] | SPRING | 3795187 |
| 19 | 333-7840 | [1] | STOP | 3337840 |
| 20 | 442-5643 | [1] | VALVE GP-PUMP CONTROL | 4425643 |
| 21 | 376-0900 Y | [1] | ROTATING GP-PUMP | 3760900 |
| 22 | 279-2491 | [1] | PLATE-PORT | 2792491 |
| 23 | 9S-8006 | [3] | PLUG (7/8-14-THD | 9S8006 |
| 24 | 3P-1210 | [1] | CONE-BEARING | 3P1210 |
| 25 | 9W-2109 | [1] | CONE-BEARING | 9W2109 |
| 26 | 455-7988 | [1] | SHAFT-PUMP | 4557988 |
| M | METRIC PART | |||
| Y | SEPARATE ILLUSTRATION |
Excavator Hydraulic Pump Assy and spare parts for Main Pump
| K3V Hydraulic pump | K3V63DT/ K3V63DTP, K3V112DT/ K3V112DTP, K3V140DT/ K3V140DTP |
| K3V180DT/ K3V180DTH, K3V280DT/ K3V280DTH | |
| K5V Hydraulic pump | K5V63/ K5V70DTP, K5V112DTP, K5V140DTP |
| MX Hydraulic motor | MX50, MX80, MX150, MX173, MX200, MX250, MX300, MX450, |
| MX500, MX530, MX750 | |
| MB Hydraulic motor | MB500, MB550, MB750 |
| M2X Hydraulic motor | M2X55, M2X63, M2X96, M2X96, M2X120, M2X128, M2X146, |
| M2X Hydraulic Swing Motor | M2X150, M2X170, M2X210 |
| M5X Hydraulic motor | M5X130, M5X160, M5X180 |
| DNB Hydraulic travel motor | DNB50B, DNB50V, DNB60B |
| HPV Hydraulic pump | Machine model |
| HPV125B Hydraulic Pump | UH07-7, UH083, UH143, UH123 |
| HPV125A Hydraulic pump | UH261, UH09-7, UH10LC-1/2, DH10 |
| HPVO55 Hydraulic Pump | EX100-3/5, EX120-3/5 |
| HPVO102 Hydraulic Pump | EX200-5, EX220-5 |
| HPVO102 Hydraulic Pump | ZAXIS200, ZAXSI220, ZAXSI250 |
| HPVO91DW Hydraulic Pump | EX200-2, EX220-2 |
| HPVO91EW Hydraulic Pump | EX200-3, EX220-3 |
| HPVO91DS Hydraulic Pump | EX100-2, EX100M-2, EX120-3 |
| HPV116C/HPV116D/ HPV116F | EX190,EX200,EX220 |
| HPV145C Hydraulic Pump | EX265-1/2/3/5, EX300-1/2/3/5 |
| HPV145D Hydraulic Pump | EX350-5, EX330-5, EX370-5 |
Huilian Machinery Excavator Hydraulic Main Pump
Excavator Hydraulic System Parts
For CATEEEEEEEEEEEEEE: E70B E110B E120 E140 E120B E180 CATEEEEEEEEEEEEEE307 CATEEEEEEEEEEEEEE308 (ARM) CATEEEEEEEEEEEEEE311 CATEEEEEEEEEEEEEE311B CATEEEEEEEEEEEEEE312 CATEEEEEEEEEEEEEE312B E200 E200B E240 E240B CATEEEEEEEEEEEEEE 303CR CATEEEEEEEEEEEEEE305.5 306E 307E 312B 312C 315 CATEEEEEEEEEEEEEE318 CATEEEEEEEEEEEEEE320 CATEEEEEEEEEEEEEE320B CATEEEEEEEEEEEEEE 320C 320D 320E CATEEEEEEEEEEEEEE322B CATEEEEEEEEEEEEEE323 324D 324E E300 E300B CATEEEEEEEEEEEEEE325 CATEEEEEEEEEEEEEE325B E330 E330B CATEEEEEEEEEEEEEE330C 330D CATEEEEEEEEEEEEEE345 345B 345C 345D 345F 349D 349F CATEEEEEEEEEEEEEE450, etc
