Pipe System Pressure Balanced Expansion Joints For Reduces Forces And Moments

bend pressure balanced mental expansion joints

Product Description

It consists of two working corrugated pipes connected by a working bellows or intermediate pipe and a balanced bellows and elbows or tees, heads, tie rods, end plates and spherical and tapered washers, etc. An expansion joint that combines axial and lateral displacement and balances the pressure thrust of the bellows.

Features

Rectangular Type Expansion Joint designed to absorb the thermal expansion of large size rectangular duct line of high temperature with low pressure temperature. Rectangular Type Expansion Joint is classified Miter (single, double) corner type. Round corner type, and Camera corner type.

Application

Gas turbine exhaust system, turbine/condenser connection, Boiler breaching, Forced draft fans, flue gas ducts, regenerators, precipitators, and other hot gas, large volume ducting systems.

Pressure -0.05MPa to 0.2 MPa
