UTP CAT6+2C Unshielded Bulk CCTV Cable 18AWG CCA Power PVC Black Jacket 8 Figure
UTP CAT6+2C Network with 18AWG CCA Power CCTV Cable Monitor Camera Wire OEM Manufacturer in China
we are professiona coaxial and lan cable manufacturer in China. Welcom to let us know your cables need.
CAT6 +2C Siamese Cable:
Spec: 4 Pair*(0.57BC+1.01PE)+rip cord+6.1PVC Gray+2C*(24*0.2CCA+1.8PVC)+5.1PVC+2C*(7*0.38CCA+1.8PE)
Packing: 100m/reel or 305m/reel
Construction Detail
| Lan Cable | Construction | Material | Diameter(mm) |
| Inner Conductor | BC | 0.57 | |
| Insulation | PE | 1.01 | |
| Outer Jacket | PVC | 6.1 | |
| DC Power | Inner Conductor | CCA | 7*0.38 |
| Insulation | PE/ PVC | 1.8 |
Electrical Characteristics
| Temperature Rating | -20℃ to 60℃ |
| Dielectric Breakdown | 2500V |
| DC Resistance/Unbalance |
28.6Ω/1000’Max/5% Max |
Networking Cable Production Line
Should I use Cat6 or Cat5e for my IP Security Cameras?
OVERVIEW
A very common question regarding security cameras and installs is the type of cabling to use. Currently, 2 types of wiring are widely used for IP security cameras which are Cat6 or Cat5e twisted pair cabling.
CAT5E
Cat5 Enhanced(cat5e) replaced the traditional Cat5 cable and introduced speeds up to ten times faster than Cat5 cable. This was considered the standard cable to use in the early 2000’s. It can handle up 1,000 Mbps of bandwidth.
CAT6
Cat6 is slowly replacing the standard cat5e cable and becoming a valid choice for many network related installs. It allows for ten times the amount of bandwidth, capable of 10,000 Mbps of bandwidth. It should be noted, though, that after 165 feet Cat6 is only capable of supporting 1,000 Mbps of bandwidth, the same as cat5e
If you have technical support from an engineer, please let us know the type of cables you need, the inner conductor, the braiding coverage, the jakcet material and color, the packing length and design, and the application. We will help you choose the most suitable cable.
If you are not sure about certain specifications of the electric cables, please let us know your inquiry and we are very happy to give you professional technical advice and support services. Our company offer specific cables and wires consulting, design, OEM and manufacturing based on the customer's requirements and application scenarios to help customers create more business opportunities.
