12.7mm Seamless Titanium Tube with 15mm and 24.5mm Hydraulic Test, Designed for Long Life Span
Price:
USD $19.5-$28.5 / kg
MOQ:
If in stock, sample is available; If not in stock,100kgs of each size
Delivery Time:
7-25 working days
Brand:
LHTI
Product Description
12.7mm Seamless Titanium Tube with 15mm and 24.5mm Hydraulic Test, Designed for Long Life Span
Product Description:
Our titanium tubes, manufactured to ASTM B338 standards, adhere to stringent quality requirements. We produce these tubes with strict compliance to ensure precise dimensions, accurate chemical composition, optimal physical properties, and high-quality surfaces. Our comprehensive quality inspections include hydraulic tests, flaw detection, ultrasonic testing, and flattening tests, all conducted in accordance with ASTM B338 standards. We also welcome third-party testing from organizations such as TUV, SGS, BV, or others, upon customer request.
Product information:
| Name | Titanium pipe / tube |
| Material | Gr1,Gr2 |
| Standard | ASTM B338 |
| Type | Seamless/welded |
| OD | 12.7mm 15mm 19.1mm 24.5mm 33.4mm 38.1mm 45mm 57mm, or as customer's request |
| Wall Thickness | 0.5-1.5mm , or as customer's request |
| Length | Max 16000mm |
| Technique | Rolled |
| status | Annealed |
| Certificate | EN 10204/3.1B, Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report---TUV,BV,SGS etc |
| Application | Heat Exchangers,Chemical industry |
Chemical composition (Wt%)
| ASTM No. | Fe max | O max | N max | C max | H max | Pd | Al | Bal |
| Grade 1 | 0.2 | 0.18 | 0.03 | 0.1 | 0.015 | - | - | Ti |
| Grade 2 | 0.3 | 0.25 | 0.03 | 0.1 | 0.015 | - | - | Ti |
Physical Properties (Min)
| ASTM Grade | Alloy Composition | Tensile Strength | Yield Strength | Elongation min % | ||
| ksi | Mpa | ksi | Mpa | |||
| Grade 1 | Unalloyed Ti ("Pure") 35A -CP1 | 35 | 240 | 25 | 170 | 30 |
| Grade 2 | Unalloyed Ti ("Pure") 50A -CP2 | 58 | 400 | 40 | 275 | 25 |
