Forged ASME B16.47 Welding Neck Pipe Flange Serises B 150#-2500# Alloy C-276 Size 2'-24'
Forged ASME B16.47 Welding Neck Pipe Flange Serises B 150#-2500# Alloy C-276 Size 2'-24'
Material:
1. Stainless Steel ASTM/ASME A/SA182 F304, F304L, F316, F316L, ASTM/ASME A/SA351 CF8, CF3, CF8M,
CF3M, DIN1.4301, DIN1.4306, DIN1.4401, DIN1.4404, DIN1.4308, DIN1.4408, DIN1.4306, DIN1.4409
2. Carbon Steel ASTM/ASME A/SA105 A/SA105N & A/SA216-WCB, DIN1.0402, DIN1.0460, DIN1.0619
Dimension:
ANSI/ASME B16.5, ANSI/ASME B16.47 Series A (MSS SP-44), ANSI/ASME B16.47 Series B (API 605),
ANSI/ASME B16.36, ANSI/ASME B16.48 (API 590)
Size: 1/2" (DN15) ~ 60" (DN1500)
Pressure: Class 150, Class 300, Class 400, Class 600, Class 900, Class1500, Class 2500
Type: Weld Neck, Threaded, Slip-On, Socket Weld, Lap Joint, Blind, Orifice Flange, Orifice Plate and Restriction Orifice Plate, Spectacle Blind, Spacer, Blanks
Face Type: Flat Face (FF), Raise Face (RF), Ring Joint (RJT)
Coating: Anti-rust Paint, Oil Black Paint, Yellow Transparent, Zinc Plated, Cold and Hot Dip Galvanized
ANSI B16.47 SERIES B FLANGES
|
ANSI B16.47 Series B Flange Classes |
||
| ANSI B16.47 Series B Class 75 Flanges | ANSI B16.47 Series B Class 150 Flanges | ANSI B16.47 Series B Class 300 Flanges |
| ANSI B16.47 Series B Class 400 Flanges | ANSI B16.47 Series B Class 600 Flanges | ANSI B16.47 Series B Class 900 Flanges |
Dimensions Weld Neck & Blind flanges ASME B16.47 Series B
Pressure Class
150 | 300 | 400 | 600 | 900
| Class 900 / 26 inch | |||||
| OD | D | B (WNF) |
B (BLF) |
H | A |
| 660.4 | 1020 | 135 141.35 |
154 160.35 |
259 265.35 |
743 |
| G | K | L | No of Bolts |
Stud Bolt Dia x L |
|
| 762 | 901.7 | 66.7 | 20 | 2.1/2 | 425 |
26 | 28 | 30 | 32 | 34 | 36 | 38 | 40 | 42 | 44 | 46 | 48
Indications:
OD = Diameter at Weld Bevel
D = Overall Diameter of Flange
B (WNF) = Minimum Thickness of Welding Neck Flange
B (BLF) = Minimum Thickness of Blind Flange
H = Length thru Hub
A = Diameter at Base of Hub
G = Outside Diameter of Raised Face
K = Bolt Circle Diameter
L = Diameter of Bolt Holes
OTHER TYPES OF FLANGES
| » | Plate Flanges | » | 300Lbs Flanges |
| » | Ring Type Joint Flanges | » | 600Lbs Flanges |
| » | Drawing Flanges | » | 900Lbs Flanges |
| » | Square Flanges | » | 1500Lbs Flanges |
| » | Nipo Flanges | » | 2500Lbs Flanges |
| » | Reducing Flanges | » | DIN Flanges PN6-PN40 |
| » | Forged Flanges | » | ASME B16.47 Series B Flanges |
| » | ANSI B16.5 Flanges | » | ANSI B16.36 Orifice Flanges |
| » | ASME B16.47 Series A Flanges | » |
150Lbs Flanges |
Product Attribute
| Place of Origin | China | Brand Name | BOYUE |
| Standard | ANSI, ISO, ASME, DIN, ASTM | Type | Weld Neck Pipe Flanges |
| ModelNumber | Alloy 600 | Thickness | #150,#300,#600,.#900,#1500,#2500 |
| Packing | Ply-Wood Cases | Payment | 30%TT+70% Balance |
Supply Ability:40000Pieces / per Month
Packaging & Delivery
Packaging Details:Generally plywooden case or following customer's requirement.
Port:Shanghai/Tianjin
Commerce Clause
| Minimum Order Quantity: | 1pcs |
| Price: | Depending on quantity |
| Payment Terms: | T/T or Western Union or LC |
| Supply Ability: | 40000pcs per month |
| Delivery Time: | 10-100 days depending on quantity |
| Packaging Details: | PLY-WOODEN CASE OR PALLET |
Why Choose Us
1.One-Stop Service,One Single Source.
2.No MOQ.
3.Best quality,competitive price
4.Fast Reply.
5.On-Time Delivery
6.Professional sales and technical team .
FAQ
