DIN 2544 Slip-On Flanges PN25 Forged/Cast Steel Flanges
| Pipe | Flange | Neck | Raised Face | Bolts |
Arropx. Weight (kg) |
||||||||||||||||
| DN |
d1 DIN (ISO)* |
D | b | k | h1 |
d3 DIN (ISO) |
s | r | h2 | d4 | f | # | Dia. of Bolt | d2 |
Weld- ing Nack |
Slip- on | Blind | ||||
| Welding Nack | Slip-on | Blind | |||||||||||||||||||
| 10 |
14 (17.2) |
90 | 16 | - | 16 | 60 | 35 |
25 (28) |
1.8 | 4 | 6 | 40 | 2 | 4 | M12 | 1/2" | 14 | 0.66 | 0.72 | 0.62 | |
| 15 |
20 (21.3) |
95 | 16 | 16 | 16 | 65 | 38 |
30 (32) |
2 | 4 | 6 | 45 | 2 | 4 | M12 | 1/2" | 14 | 0.76 | 0.81 | 0.74 | |
| 20 |
25 (26.9) |
105 | 18 | 18 | 18 | 75 | 40 |
38 (40) |
2.3 | 4 | 6 | 58 | 2 | 4 | M12 | 1/2" | 14 | 1.06 | 1.24 | 1.05 | |
| 25 |
30 (33.7) |
115 | 18 | 18 | 18 | 85 | 40 |
42 (45) |
2.6 | 4 | 6 | 68 | 2 | 4 | M12 | 1/2" | 14 | 1.3 | 1.38 | 1.31 | |
| 32 |
38 (42.4) |
140 | 18 | 18 | 18 | 100 | 42 |
52 (56) |
2.6 | 6 | 6 | 78 | 2 | 4 | M16 | 5/8" | 18 | 1.88 | 2.03 | 1.82 | |
| 40 |
44.5 (48.3) |
150 | 18 | 18 | 18 | 110 | 45 |
60 (64) |
2.6 | 6 | 7 | 88 | 3 | 4 | M16 | 5/8" | 18 | 2.33 | 2.35 | 2.11 | |
| 50 |
57 (60.3) |
165 | 20 | 20 | 20 | 125 | 48 |
72 (75) |
2.9 | 6 | 8 | 102 | 3 | 4 | M16 | 5/8" | 18 | 2.82 | 3.20 | 2.91 | |
| 65 | 76.1 | 185 | 22 | 22 | 22 | 145 | 52 | 90 | 2.9 | 6 | 10 | 122 | 3 | 8 | M16 | 5/8" | 18 | 3.74 | 4.29 | 4.13 | |
| 80 | 88.9 | 200 | 24 | 24 | 24 | 160 | 58 | 105 | 3.2 | 8 | 12 | 138 | 3 | 8 | M16 | 5/8" | 18 | 4.75 | 5.88 | 5.21 | |
| 100 | 108 (114) | 235 | 24 | 24 | 24 | 190 | 65 |
128 (134) |
3.6 | 8 | 12 | 162 | 3 | 8 | M20 | 3/4" | 23 | 6.52 | 7.54 | 7.08 | |
| 125 |
133 (139) |
270 | 26 | 26 | 26 | 220 | 68 |
155 (162) |
4 | 8 | 12 | 188 | 3 | 8 | M24 | 7/8" | 27 | 9.07 | 10.8 | 10.4 | |
| 150 |
159 (168) |
300 | 28 | 28 | 28 | 250 | 75 |
182 (192) |
4.5 | 10 | 12 | 218 | 3 | 8 | M24 | 7/8" | 27 | 11.8 | 14.5 | 13.9 | |
| 200 |
216 (219) |
360 | 30 | 30 | 30 | 310 | 80 | 244 | 6.3 | 10 | 16 | 278 | 3 | 12 | M24 | 7/8" | 27 | 17 | 22.3 | 21.5 | |
| 250 |
267 (273) |
425 | 32 | 32 | 32 | 370 | 88 |
292 (298) |
7.1 | 12 | 18 | 335 | 3 | 12 | M27 | 1" | 30 | 24.4 | 33.5 | 32.5 | |
| 300 |
318 (323) |
485 | 34 | 34 | 34 | 430 | 92 | 352 | 8 | 12 | 18 | 395 | 4 | 16 | M27 | 1" | 30 | 31.2 | 46.3 | 44.7 | |
| 350 |
368 (355) |
555 | 38 | 38 | 38 | 490 | 100 | 398 | 8 | 12 | 20 | 450 | 4 | 16 | M30 | 1-1/8" | 33 |
44.2 47.2 |
68.0 | 65.9 | |
| 400 |
419 (406) |
620 | 40 | 40 | 40 | 550 | 110 | 452 | 8.8 | 12 | 20 | 505 | 4 | 16 | M33 | 1-1/4" | 36 |
58 62 |
89.7 | 87.0 | |
| 500 |
521 (508) |
730 | 44 | 44 | 44 | 660 | 125 | 558 | 10 | 12 | 20 | 615 | 4 | 20 | M33 | 1-1/4" | 36 | 89.6 | 138 | 134 | |
