Anti Corrosion Boiler Carbon Steel Pipe OD 19.05mm - 168.3mm High Hardness
Anti Corrosion Boiler Carbon Steel Tube OD 19.05mm - 168.3mm High Hardness OD1/2'-48'
Standard: JIS G3461
Main steel grades: STB340, STB410, STB510
Application: JIS G3461 steel tube can be widely used as boiler water tube, smoke tube, superheater tube, air preheating tube, accessories for transferring heat inside and outside the pipe.
Chemical Requirements & Mechanical Proterties:
| Standard | Grades | Chemical composition | |||||||||
| C | Si | Mn | P | S | Cr | Mo | Cu | Ni | V | ||
| JIS G3461 | STB340 | ≤0.18 | ≤0.35 | 0.30～0.60 | ≤0.035 | ≤0.035 | / | / | / | / | / |
| STB410 | ≤0.32 | ≤0.35 | 0.30～0.80 | ≤0.035 | ≤0.035 | / | / | / | / | / | |
| STB510 | ≤0.25 | ≤0.35 | 1.00～1.50 | ≤0.035 | ≤0.035 | / | / | / | / | / | |
| Standard | Grades |
Tensile strength (MPa) |
Tensile strength (MPa) |
Elongation (%) |
| JIS G3461 | STB340 | ≥340 | ≥175 | ≥35 |
| STB410 | ≥410 | ≥255 | ≥25 | |
| STB510 | ≥510 | ≥295 | ≥25 |
Mark: As required.
Inspection and Test: chemical composition test, mechanical properties test(tensile, yield, elongation), process properties test(flatting, flaring, bending, hardness, impact, etc.), appearance and size test, non-destructive inspection test, hydrostastic test.
Delivery status: Annealed, normalized, normalized+Tempered, etc.
End: plain end, beveled end, threaded
End protection: plastic caps
Outside coating: black painting, anti-corrosion oil,galvanized finish, finish as per customer requirements.
Packing: Exporting package/wooden box /as requirement.
| Place of Origin | China | Brand Name | BOYUE |
| Standard | ANSI, ISO, ASME, DIN, ASTM | Type | Seamless |
| ModelNumber | Carbon Steel Pipe | Thickness | SCH 5-SCH XXS |
| Packing | Depending on customer | Payment | 30%TT+70% Balance |
Supply Ability:40000Pieces / per Month
Packaging & Delivery
Packaging Details:Generally plywooden case or following customer's requirement.
Port:Shanghai/Tianjin
| Minimum Order Quantity: | 1pcs |
| Price: | Depending on quantity |
| Payment Terms: | T/T or Western Union or LC |
| Supply Ability: | 40000 ton per month |
| Delivery Time: | 10-100 days depending on quantity |
| Packaging Details: | Depending on customer |
Why Choose Us
1. One-Stop Service,One Single Source.
2. No MOQ.
3. Best quality,competitive price
4. Fast Reply.
5. On-Time Delivery
6. Professional sales and technical team .
FAQ
Q1: Are you a factory or a trade company?
A1: We are a professional manufacturer for designing and producing of Large-size products.(View Mor)
Q2: Do you make customized products or finished parts?
A2: All parts are custom made only, and in stock, we can produce based on your drawings.
Q3: Will my drawing be e after you get it?
A3: Yes, we will not release your design to third party unless with your permission.
Q4: What is the MOQ?
A4: Small order is acceptable, but the more, the cheaper.
Q5: How about the samples?
A5: We are happy to make prototype part or sample for clients to ensure quality standard, but it’s charged according to your drawing.
