Carbon Seamless Steel Pipe API 5L A106 GR B ERW LSAW SSAW SCH 40 Wear Resistant
Carbon Steel Seamless Steel Pipe API 5L A106 GR.B ERW / LSAW / SSAW Sch 40 OD1/2'-48
Scope of the seamless steel pipe we produce:
| Manufacturer Pipe Steel Pipe |
Shandong Huitong Steel Pipe Manufacturing Co.,Ltd. |
|||
| Brand Name | qiluhuitong | |||
| Business Type | Manufacture & Sales | |||
| Product Description | Caron & Low Alloy Seamless Steel Pipe | |||
| Advantaged Product Specification | ||||
| English | Chinese | |||
|
Outside Diameter (Inch) |
Wall thickness (Inch) |
Outside Diameter (mm) |
Wall thickness (mm) |
|
| From 1/2 to 5 | From SCH40 to XXS | From 25 to 356 | From4 to 80 | |
| Length | From 2m to 12.5m in accordance with customers' requirements | |||
|
Material & Standard Description |
Chisese | American | German | |
| 10# | ASTM A53-A | St37 DIN1626 | ||
| ASTM A106-A | St37-2 DIN17175 | |||
| ASTM A179-C | St35.8 DIN17175 | |||
| ASTM A192 | St35.8 DIN17175 | |||
| 20# | ASTM A53-B | St42-2 DIN1626 | ||
| ASTM A106-B | St45-8 DIN17175 | |||
| ASTM A178-C | St45-4 DIN1629 | |||
| 45# | ASTM A1045 | CK45 | ||
| 16Mn | ASTM A210-C | St52 DIN1629 | ||
| 37Mn5 | J55 | |||
| 27SiMn | ||||
| CrMo | ASTM 4135,4150 | CrMo4 DIN17212 | ||
| 40Cr | ASTM 5140 | 41Cr4 | ||
Carbon Steel Seamless Pipes Details:
Material Grades
| High Temperature Seamless Pipe | ASTM A106 Gr. B/C, API 5L Gr. B, ASTM A53 Gr. B |
| Heat Exchanger Seamless Tube | ASTM A179 |
| Low Temperature Seamless Pipe | ASTM A333 Gr. 3/6 |
| Low Temperature Seamless Tube | ASTM A334 Gr. 6 |
| High Yield Seamless Pipe | API 5L Gr. X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2 |
| High Yield Seamless Pipe | ISO 3183 Gr.L245, L290, L320, L360, L390, L415, L450, L485 |
| Atmospheric & Low Temp EFW Pipes | ASTM A671 Gr. CC60/CC65/CC70 |
| High Pressure & Moderate Temp EFW Pipes | ASTM A672 Gr. B60/B65/B70/C55/C60/C65/C70 |
| High Yield ERW/SAW Pipe | API 5L Gr. X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2 |
| High Yield ERW/SAW Pipe | ISO 3183 Gr.L245, L290, L320, L360, L390, L415, L450, L485 |
Additional Testing : NACE MR0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc.
Dimensions : All Pipe is manufactured and inspected/tested to the relevant standards including ASTM, ASME, API.
| High Temperature Seamless Pipe | ASTM A106 Gr. B/C, API 5L Gr. B, ASTM A53 Gr. B |
| Heat Exchanger Seamless Tube | ASTM A179 |
| Low Temperature Seamless Pipe | ASTM A333 Gr. 3/6 |
| Low Temperature Seamless Tube | ASTM A334 Gr. 6 |
| High Yield Seamless Pipe | API 5L Gr. X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2 |
| High Yield Seamless Pipe | ISO 3183 Gr.L245, L290, L320, L360, L390, L415, L450, L485 |
| Atmospheric & Low Temp EFW Pipes | ASTM A671 Gr. CC60/CC65/CC70 |
| High Pressure & Moderate Temp EFW Pipes | ASTM A672 Gr. B60/B65/B70/C55/C60/C65/C70 |
| High Yield ERW/SAW Pipe | API 5L Gr. X42/X46/X52/X56/X60/X65/X70/X80 PSL-1/PSL-2 |
| High Yield ERW/SAW Pipe | ISO 3183 Gr.L245, L290, L320, L360, L390, L415, L450, L485 |
Additional Testing : NACE MR0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc.
Dimensions : All Pipe is manufactured and inspected/tested to the relevant standards including ASTM, ASME, API.
Carbon steel pipe astm specifications Chemical Composition
| Grade | C≤ | Mn | P≤ | S≤ | Si≥ | Cr≤ | Cu≤ | Mo≤ | Ni≤ | V≤ |
| A | 0.25 | 0.27-0.93 | 0.035 | 0.035 | 0.10 | 0.40 | 0.40 | 0.15 | 0.40 | 0.08 |
| B | 0.30 | 0.29-1.06 | 0.035 | 0.035 | 0.10 | 0.40 | 0.40 | 0.15 | 0.40 | 0.08 |
| C | 0.35 | 0.29-1.06 | 0.035 | 0.035 | 0.10 | 0.40 | 0.40 | 0.15 | 0.40 | 0.08 |
Carbon steel pipe astm specifications Mechanical Properties
| Grade | Rm Mpa Tensile Strength | Mpa Yield Point | Elongation | Delivery Condition |
| A | ≥330 | ≥205 | 20 | Annealed |
| B | ≥415 | ≥240 | 20 | Annealed |
| C | ≥485 | ≥275 | 20 | Annealed |
Packing of Carbon Seamless steel pipe
-- Big OD:in bulk
-- Small OD:bundled by steel strips
-- Nomal OD:bundled by 4 to 8 heavy steel strips with plastic tarpaulin clin cover all the
bundles including two slings of the bundle with two steel tags
Shipping of Carbon Seamless steel pipe
| Container Loading Capacity | |||||
| Type | Length | Width | Height | Volume | Max Weight |
| 20FT GP | 5.8m | 2.13m | 2.18m | 24-26 CBM | 25 MT |
| 40FT GP | 11.8m | 2.13m | 2.18m | 54 CBM | 25 MT |
| 40FT HP | 11.8m | 2.13m | 2.72m | 68 CBM | 26 MT |
| According to the quantity or volume,you can choose! | |||||
| FCL(full container load); LCL(less than container load); or Bulk-cargo. | |||||
|
Place of Origin |
China | Brand Name | BOYUE |
| Standard | ANSI, ISO, ASME, DIN, ASTM | Type |
Seamless |
| ModelNumber | Carbon Steel Pipe | Thickness | SCH 5-SCH XXS |
| Packing | Depending on customer | Payment | 30%TT+70% Balance |
Supply Ability:40000Pieces / per Month
Packaging & Delivery
Packaging Details:Generally plywooden case or following customer's requirement.
Port:Shanghai/Tianjin
Commerce Clause
| Minimum Order Quantity: | 1pcs |
| Price: | Depending on quantity |
| Payment Terms: | T/T or Western Union or LC |
| Supply Ability: | 40000 ton per month |
| Delivery Time: | 10-100 days depending on quantity |
| Packaging Details: | Depending on customer |
Why Choose Us
1.One-Stop Service,One Single Source.
2.No MOQ.
3.Best quality,competitive price
4.Fast Reply.
5.On-Time Delivery
6.Professional sales and technical team .
FAQ
Q1: Are you a factory or a trade company?
A1: We are a professional manufacturer for designing and producing of Large-size products.(View Mor)
Q2: Do you make customized products or finished parts?
A2: All parts are custom made only, and in stock, we can produce based on your drawings.
Q3: Will my drawing be e after you get it?
A3: Yes, we will not release your design to third party unless with your permission.
Q4: What is the MOQ?
A4: Small order is acceptable, but the more, the cheaper.
Q5: How about the samples?
A5: We are happy to make prototype part or sample for clients to ensure quality standard, but it’s charged according to your drawing.
