Product Description
U Type Trough Screw Conveyor Machine are spiral bulk material transportation systems that convey raw ingredients to and from processing areas that are on different levels of a facility. These conveyors can horizontal transport materials, also it can slanted at different angles to economically elevate and convey materials up and down floors. They require ample space and an increased amount of power to lift the material, depending on the steepness of the angle.
Main Parameters
| LS type | 160 | 200 | 250 | 315 | 400 | 500 | 630 | 800 | 1000 |
| GX type | 200 | 250 | 300 | 400 | 500 | ||||
| Screw diameter(mm) | 160 | 200 | 250 | 315 | 400 | 500 | 630 | 800 | 1000 |
| Sc Screw pitch(mm) | 160 | 200 | 250 | 315 | 355 | 400 | 450 | 500 | 560 |
| Rotate speed(r/min) | 60 | 50 | 50 | 50 | 50 | 50 | 50 | 45 | 35 |
| Capacity (m³/h) | 7.6 | 11 | 22 | 36.4 | 66.1 | 93.1 | 160 | 223 | 304 |
| Pd1=10m(kw) Power | 1.5 | 2.2 | 2.4 | 3.2 | 5.1 | 5.1 | 8.6 | 12 | 16 |
| Pd1=30m(kw) Power | 2.8 | 3.2 | 5.3 | 8.4 | 11 | 15.3 | 25.9 | 36 | 48 |
Main Features
1. It is suitable for small-scale operation, with stable transmission, and can play a good role in the case of limited transportation site.
2. It has good sealing performance, and has great advantages for occasions with large dust and environmental requirements.
3. It can avoid the occurrence of dust during the transportation process.
4. The U-shaped screw conveyor is not suitable for long-distance transportation, and the cost is larger than that of the belt conveyor, and it is easy to cause crushing and other damage to fragile materials.
Packing & Shipping
Well-designed packing and transportation ensure that the products can be delivered intactly to our customers.
