Carbon Steel Automatic Screw Feeder Machine For Cement
Factory Price Automatic Screw Feeder Machine For Cement
Product Description
Screw Feeder Machine is the ideal solution for hard-to-transport materials ranging from irregularly shaped dry solids such as scrap wood and metals, to semiliquid and sticky materials including pulp, compost,food-processing waste, hospital waste, and wastewater products.
Screw Feeder Machine consists of rotating shaftless screw inside U-shaped trough having an inlet hopper and outlet spout,being the rest of conveyor completely closed. The feed is pushed into the feed inlet and then moves to the outletspout under thepushing of the screw.
Main Parameters
| Model | WLS150 | WLS200 | WLS250 | WLS300 | WLS400 | WLS500 | ||
| Screw diameter(mm) | 150 | 184 | 237 | 284 | 365 | 470 | ||
| Thickness of screw blade | 14/20mm | 14/20mm | 16/20mm | 18/20mm | 18/20mm | 18/20mm | ||
| Thickness of liner board | 8-10mm | 10mm | 10mm | 10mm | 10mm | 10mm | ||
| Diameter of shell | 180 | 219 | 273 | 351 | 402 | 500 | ||
| Operating angle(α) | 0-45° | ≤30° | ≤30° | ≤30° | ≤30° | ≤30° | ||
| Max delivery length(m) | 12 | 13 | 16 | 18 | 22 | 25 | ||
| Capacity(t/h) | 2.4 | 7 | 9 | 13 | 18 | 28 | ||
|
|
Model | L≤7 | Y90L-4 | Y100L1-4 | Y100L2-4 | Y132S-4 | Y160M-4 | Y160M-4 |
| Power | 1.5 | 2.2 | 3 | 5.5 | 11 | 11 | ||
| Model | L>7 | Y100L1-4 | Y100L2-4 | Y112M-4 | Y132M-4 | Y160L-4 | Y160L-4 | |
| Power | 2.2 | 3 | 4 | 7.5 | 15 | 15 | ||
Features of Screw Feeder Machine
♦ Ease of installation, stable operation
♦ Automatic controlled, low noise, lowleakage
♦ Internal bearings are eliminated, lowmaintenance
♦ Long service life, low total cost of ownership
♦ Improved conveying efficiency whencompared to other types of conveyors
♦ Allows greater flexibility for plant layout due to configurations available
Application
The screw feeder machine are the ideal solution for hard-to-transport materials ranging from irregularly shaped dry solids such as scrap wood and metals, to semiliquid and sticky materials including pulp, compost, food-processing waste, hospital waste, and wastewater products.
